4
E7 IC Card Reader Introduction
1.1 Overview
E7 password keyboard is the smart IC Card Reader，meet ISO14443A and ISO 7816 standard，
support contactless IC card，such as Mifare s50、s70、Utrlight and CPU card，and contact CPU
card. E7 smart IC Reader contains LCD display（2 rows）and simple keyboard,，that meet the
demand of entering the password or consumption data and displaying the results in the processing
of user’s operation. And E7 smart IC Reader supports USB interface that meets HID protocol.
In order to improve safety factor, users can configurate a standard SAM card that meets ISO
7816-3 and GSM11.11 protocol in the device.
Cards supported：
PHILIPS Company:MF1ICS50、FM1108、MF1ICS70、contactless CPU card\contact CPU card.
E7 IC card reader widely used in financial payment 、 E-commere payment system 、 One-Card
consume system and supply chain management.
1.2 Features
Support Protocol：ISO14443 A/ ISO7816
Recognition Distance：0-50mm
Physical Interface：USB or Serial port
Communication Rate：9600bps～115200bps
Operating System：Windows 98 、 Me 、 2K 、 XP 、 2003、Vista 及 Linux
LED Display：128*64 dot matrix display LCD screen (can display two lines in both Chinese and
English)
Working Frequency：13.56MHZ
Working Voltage：DC5V ± 10%
Data Storage Capacity：the standard configuration of storage is 2K bytes in the reader (can expand
according to user’s demand)
Status Display：LED light，indicate power or communication status，user can control buzzer
Dimensions：Length×Width×Hight：155*100*80 mm
Weight：about 322g
1.3 Device Interface
Rs232 or USB E7
Built-in antenna
DC5V Power
RS232 Serial interface or USB used for communication with PC .
RF Card
