69
Example：the corresponding address of the
second sector KeyA is 4004
AES sector key
4040h ~ 404Fh
AESsector key 0~31sector，
The second byte defines the sector NO.and
KeyA/KeyB
KeyA = 2* Sector
KeyB = 2* Sector + 1
A special secret key
8000
It is determined by the manufacturer and
can not be change
The master secret key
9000
Can apply to change the switch key、card’s
configuration key 、 the value of MFP
configuration、install identifier、ATS and
itself
Card’s configuration key
9001
Apply to change the domain configuration
block、the key of virtual card and itself
The two-level conversion key
9002
Upgrade to the two-level
The three-level conversion key
9003
Upgrade to the three-level
The verification key of one-level
card
9004
Extra AES verification key of one-level
card
Selection key of virtual card
A000
Count the key of MAC under virtual card
Verify key to the nearest
A001
Verify and count MAC to the nearest
Virtual card poll the key of ENC
A080
Select virtual card to poll ENC
Virtual card poll the key of MAC
A081
Select virtual card to poll MAC
