Data Sheet

Key Features
• Ceramic Heater
• Vacuum & Release
• Vacuum Gauge
Options
• Starter Pack of Plastic
• Spare Parts Kit
Forming Area (mm / inches) Sheet Size (mm / inches) Max Depth of Draw Max Material
Thickness
Heating Zones Heater Type
368 x 368mm / 14.5 x 14.5" 406 x 406mm / 16 x 16" 152mm / 6" 3mm / 0.12" 1 Ceramic
Width Height Depth Weight Single Phase Power
Requirements
Power Consumption Air
Requirements
635 mm / 25” 530 mm / 20” 1140 mm / 45” 75kg / 165lbs 15A / 120V / 60Hz 1.5kW n/a
Technical Specifi cations
Newform1616
Desktop Thermoforming Machine
Formech sets a new benchmark for entry level vacuum
forming under the NewForm brand, designed and built
entirely in-house by Formech in the USA.
Specifi cally designed for students, hobbyists and
product designers, the NewForm 16:16 offers
professional forming capability in a Plug and Play
package with an integrated diaphragm vacuum pump.
NewForm 16:16 can accommodate a sheet size of
16” x 16” and effortlessly form a wide range of sheet
materials up to 0.12” thick and a depth of 6”. The fully
optimized heating profi le is made up of 13 individual
ceramic elements operated by a single zone control.
Intuitive controls, rugged construction and professional
forming capability all add up to make the NewForm
16:16 unbeatable at the price.
Formech machine features and specifi cations are subject to change without notice as part of our continual product development programme.
For more information and product videos formechdirect.com
Key Features
• Ceramic Heater
• Vacuum & Release
• Vacuum Gauge
Options
• Starter Pack of Plastic
• Spare Parts Kit
