GENERAL INFORMATION Main Features For your Safety Unpacking General Operation RCU Front Panel Rear Panel 1 1 2 3 3 4 5 5 INSTALLATION 6 MENU INFORMATION 7 Main Menu 1. Channel List 1.1 TV Channel List 1.2 Radio Channel List 1.3 Delete All 2. Installation 2.1 Antenna Connection 2.2 Satellite List 2.3 Antenna Setup 2.4 Single Satellite Search 2.5 Multi Satellite Search 2.6 TP List 3. System Setup 3.1 Language 3.2 TV 3.3 Local Time setting 3.4 Timer Setting 3.5 Parental Control 3.6 OSD Setting 3.
4. Tools 4.1 Information 4.2 Factory Setting 4.3 SatcoDx Auto Programing 5. Game 6. Hot key 6.1 Info 6.2 EPG 6.3 Find 6.4 Numer 6.5 TV/Radio 6.6 Up/Down 6.7 Left/Right 6.8 Mute 6.9 Pause 6.10 OK 6.11 Audio 6.12 Recall 6.13 Fav 6.14 Teletext 6.
A Digital Satellite Receiver is a convenient product that allows you to view a variety of programs provided through satellite. This user's guide covers the installation of the DSR and the necessary steps to implement various features. This also explains special features available only in this DSR in detail, which will allow you to make full use of these feature. Information confirmed in this document is subject to change.
For Your Safety To avoid electric-shock hazards, do not open the cabinet, refer servicing to qualified personnel only. Keep the receiver away from flower vases, tubs, sinks, etc., in order to avoid damaging the equipment. Do not expose the receiver un-der the sunlight. And keep it away from the heat source. Do not block ventilation holes of the Receiver so that air can circulate freely. When the abnormal phenomenon occur, you should cut off the power immediately.
DE AB .,*? MN JK GH W XY TU RS O L I PQ F C !@ Z V . PR + OK T LI S EX IT PR V FA SL TV EE P L R /AV TX T SA ZO FI T OM IN FO ND R Remote Control Batteries User's Guide General Operation Throughout this manual you will notice that the everyday operation of the receiver is based on a series of user friendly on screen display and menus.
RCU Key Function Turns power ON/OFF of the DSR .,*?!@ ABC DEF GHI JKL MNO PQRS TUV WXYZ When watching a channel, mute the sound 0~9 TV/RADIO PR Enter number of the required menu item or select a channel number to watch Switches between TV and Radio mode Switches back to previous channel .
Front Panel Rear Panel CONNECT TO A DIGITAL AMPLIFIER CONNECT TO A PC FOR S/W UPGRADE CONNECT TO TV USING A SCART CABLE CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER CONNECT VIDEO TO TV USING RCA JACK CONNECT TO TV ANT INPUT LNB IN: CONNECT TO SATELLITE ANTENNA Connecting to TV using SCART support Satellite Dish DSR IN TV SCART The picture is only for reference,please make the object as the standard.
Connecting to TV using RCA support IN VIDEO AUDIO TV Satellite Dish R L DSR Connecting to Digital Amplifier Satellite Dish IN TV DIGITAL AUDIO CONVERTOR OR AMPLIFIER L R DIGITAL AUDIO SPEAKER The picture is only for reference,please make the object as the standard.
Main Menu Make sure that you have properly installed and connected the cables of the receiver well. If the receiver is the factory status or there is no program list, when power on, the Main Menu window will be displayed on the screen. During the normal TV/Radio mode, press MENU key on the RCU to enter into the Main Menu window. This menu consists of 5 major main menus as follow.
If there is no program, you can not exit from the Main Menu window by pressing MENU or EXIT key. System will inform "No channel" and the following items turn grey.
3. Press FAV key to move the FAV button upward. Select the program and press OK key to pop up the favourite group list. In the list, select the group that you want to add into and press OK key, and then you will find the favourite mark is displayed at the right side of the selected program. Press FAV key again to exit from the fav mode, and you will find the FAV button return to the origin position. 4. Press red colour key to move the Lock button upward.
6. Press yellow colour key to move the Move button upward. Select the program and press OK key to mark this program with the move mark. Press PR+, PR- keys to move the cursor to the position where you want to locate and press OK key to confirm. Press yellow colour key again to exit from the yellow mode, and you will find the yellow button return to the origin position. 7. Press blue colour key to enter into the Edit channel window. i .
ii. Edit (green colour key) Press green colour key to move the Edit button upward. Select the program and press OK key to pop up the Rename window. In Rename window, press red colour key to switch between capital letter and lower letter; press green colour key to delete the character on the cursor; press keys to move the cursor left or right; press numeric keys (0-9) to input the character, please refer to the down table. Press yellow colour key to save and exit, or press blue key to cancel and exit.
iii. Delete (blue colour key) In Delete window, press blue colour key to move the Delete button upward. Select the program and press OK key to mark this program with the deletion mark. You can cancel this mark by pressing OK key again. Press EXIT key to pop up the dialogue "Are you sure to save?". Select Yes button and press OK key to save, or select NO button and press OK key to exit without saving. 1.2 Radio Channel List Sine the same operation as 1.1 TV Channel List, here we don't explain any more. 1.
2. Installation 1. Press OK key or key to pop up the "Input Password" dialogue, you can not enter into the menu unless the correct password is inputted. The default password is "0000". 2. Press PR+, PR- keys to move the cursor up or down. 3. Press EXIT key or key to move the focus to the left menu. 2.1 Antenna Connection Press keys to select between Motor Antenna and Fixed Antenna. 2.2 Satellite List 1. Press PR+, PR- keys to select the satellite up or down.
3. Press red colour key to pop up the Edit Satellite window. Press PR+, PR- keys to move cursor up or down. Name: User numeric keys to change the name of the satellite, please refer to the Edit Channel Name. Longitude: You can press keys to switch between east longitude and west longitude. After pressing OK key, you can use numeric keys to edit the longitude, press EXIT key or the PR+, PR- keys to exit editing mode. The range of the longitude is from 1to 180 degree.
2.3 Antenna Setup Part A: Fixed Suppose that you have selected Fixed Antenna in the Antenna Connection window. 1. Satellite: All selected satellites in the satellite list are displayed in this item. Press keys to select the satellite in circle. Or press OK key to pop up the dropdown list, then select the desired satellite in the list and press OK key to confirm. 2. LNB Freq, Transponder, DiSEqC1.0, DiSEqC1.1: The same operation as the above. 3.
4. Motor Setting: Press OK key to the Motor Setting window. Satellite: Press keys to select the satellite in circle. Or press OK key to pop up the drop-down list, then select the desired satellite in the list and press OK key to confirm. Transponder: The same operation as the above. Position No., & Save: The range is from 0 to 63. "0" delegates the original position. You can select the proper value when you has rotated the antenna.
6. If select USALS, Delete All item will turn grey. Local Longitude, Local Latitude: Press keys to switch between West and East, or press keys to switch between North and South. Press OK key to enter into the editing mode. Use numeric keys (0-9) to input the longitude or latitude, press MENU key or EXIT key to exit. The range of the longitude is from 0 to 180,while the range of the latitude is from 0 to 90.
4. Network Search: Select between No and Yes. This item turns grey when Auto Scan is selected in the following Scan mode item. 5. Scan Mode: Press keys to select between Auto Scan and Preset Scan. Auto Scan is Blind scan, while Preset Scan is to search the preset frequencies. 6. Search: Press OK key to start searching. 2.5 Multi Satellite Search From the Multi Satellite Search window, you can search several satellites at the one time. 1.
2. Press red colour key to pop up the Edit TP window. Frequency, Symbol rate: Press keys to add or reduce by step one. Or press numeric keys (0-9) to input the desired value. The range of the frequency is 300013450, while the range of the symbol rate is 1000~45000. The inputted value is beyond this range, the value will return to the origin value. Polarity: Press keys to switch between Vertical and Horizontal. 3. Press green colour key to pop up the Add TP window.
3. System Setup 1. Press OK key or key to move the cursor to the right menu. 2. Press PR+, PR- keys to move the cursor up or down. 3. Press EXIT key or key to move the focus to the left menu. 3.1 Language 1. Press OK key to enter into the Language window. Press keys to select the language in circle, while press PR+, PRkeys to move the cursor up or down in circle. 2. Press MENU key or EXIT key to save and exit. 3. The types of the language, pleaser refer to the configuration of the customer. 3.
3.3 Local Time Setting 1. Summer Time: Select between ON and OFF. "OFF" delegates the normal time. If select ON, time will add one hour. 2. GMT Offset: When select "ON" in GMT Usage item, system will get the date and time information from the screen automatically. Date and Time two items will turn grey. Select the proper option in the GMT Offset item. The default setting is GMT ON. 3.Date, Time: When select "OFF" in GMT Usage, Date and Time two items take effect, while GMT Usage turns grey.
3.5 Parental Lock Before entering into the Parental Lock window, you need input the correct password. The default password is 0000. 1. Menu Lock: Press keys to select between Off and On. If select "On" , you can not enter into the most window before entering the password. 2. Channel Lock: Press keys to select between Off and On. The default value is Off. If select "On", you can not view the locked channel set in Chanel List Edit window until you have inputted the correct password. 3.
3.7 Favorite There are 32 favorites group listed in this window. Press PR+, PR- keys to select one and press OK key to the Rename window. Since the same operation as the above the Add Satellite window, here we don't explain any more. 3.8 Other 1. LNB Power: Select between Off and On. 2. Channel Play Type: Select among All, Free, Scramble. 3. Channel Change: Select between Freeze and Black screen. 4. Beeper: Select between Off and On.
4. Tools 1. Press OK key or key to pop up the "Input Password" dialogue, you can not enter into the menu unless the correct password is inputted. The default password is 0000. 2. Press PR+, PR- keys to move the cursor up or down. 3. Press EXIT key or key to move the focus to the left menu. 4.1 Information Press OK key to the Information window. 4.2 Factory Setting Press OK key to enter into the Factory Setting window. Select Yes button and press OK key to return to the factory setting.
4.3 SatcoDX Auto Programing Press OK key at the Start button to start receiving date from RS232 for 10 seconds. 5. Game 1. Press OK key or key to enter into the game. 2. Press PR+, PR- keys to move the cursor up or down. 3. Press EXIT key or key to move the focus to the left menu. 4. Select the game that you want to play and press OK key to enter into the window.
6. Hot Key 6.1 Info Press INFO key to pop up the Info bar. Press INFO key again to pop up the program guide of the current program. You can press keys to know the program guide of the future 16 days. 6.2 EPG Press EPG key to enter into the EPG window. 1. Press PR+, PR-, keys to select up or down, left or right. 2. Press red colour key to pop up the Time Bar window. Press PR+, PR- keys to select up or down, while press keys to select left or right in the time bar.
6.3 Find Press FIND key on to pop up the Find window. Use numeric keys to enter into the character and use the colour keys to realized the corresponding operation. 6.4 Number Use the numeric keys (0-9) to input the number of the desired channel. If the inputted number is beyond the valid channel number, system will "No such a channel" and press OK key to close this message. 6.5 TV/RADIO In normal mode, press TV/RADIO key to switch between TV mode and Radio mode. 6.
6.11 Audio 1. Press keys to enter into the Audio window. 2. Press keys to select among Left, Right, Stereo, and Mono. 3. Changing the audio mode is only connected with the current channel, not all the channels. 4. Press MENU or EXIT key to close this window. 6.12 Recall Press key to switch the current channel to the previous channel. 6.13 FAV 1. Press FAV key to pop up the favourite group window. 2. Press keys to select the favorite group. Press PR+, PR- keys to select the channel up or down..
Problem Possible causes What to do The display on the front panel does not light up. Main cable is not connected. Check that the main cable is plugged into the power socket. No sound or picture, but the front panel shows red light. The receiver is in standby mode. Press the standby button. The satellite dish is not pointing at the satellite. Adjust the dish. Check the signal level in the Antenna Setup menu. No signal or weak signal.
