The Celsius series builds upon proven technology with cutting edge advancements

and premium sound dampening materials to deliver extreme cooling performance

with minimum noise output.

Smart dual mode speed controls are both simple and robust with no need for

additional software. Both fan and pump speeds can be managed by an intelligent

auto mode or switched to PWM mode for precise user control.

For true enthusiasts, the satisfaction of a clean and efficient build can never be

overstated, and the Celsius makes this easier than ever with an integrated fan hub

and concealed cable routing.

Celsius series

The Cool, Silent Type

Produc t Sheet

Summary of content (5 pages)

PAGE 1
P r o d u c Celsius series The Cool, Silent Type The Celsius series builds upon proven technology with cutting edge advancements and premium sound dampening materials to deliver extreme cooling performance with minimum noise output. Smart dual mode speed controls are both simple and robust with no need for additional software. Both fan and pump speeds can be managed by an intelligent auto mode or switched to PWM mode for precise user control.
PAGE 2
P r o d u c t S h e e t Key features ● The Celsius series uses a combination of cutting edge technology and premium sound dampening materials to deliver extreme cooling performance with minimum noise output. ● An intelligent temperature-controlled auto mode adjusts fan and pump speeds in real-time for optimum balance of cooling performance and silence, while PWM mode enables precision manual tuning for any usage situation.
PAGE 3
P r o d u c t S h e e t General specifications Specification Coldplate technology Coldplate material Additional sound dampening Thermal paste Sockets supported (Intel) Tube length Tube material Fittings, block side Fittings, radiator side Thermal paste Fan control Warranty • Celsius S24 • Fifth generation • Copper • Integrated • Pre-applied, high thermal conductivity • 1150, 1151, 1155, 1156, 1366, 2011, 2011-v3, 2066 (via included 2011-v3 kit) • AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+, TR4
PAGE 4
P r o d u c t S h e e t General specifications Fan specification Fan type Rotational speed Bearing PWM control Acoustical noise (full speed) Maximum air flow Maximum static pressure Input voltage Maximum input current MTBF • Celsius S24 • Fractal Design Dynamic X2 GP-12 PWM • 500-2000 RPM • LLS bearing • Yes • 32.2 dB(A) • 148.8 m3/h | 87.6 CFM • 2.30 mm H2O • 12 V DC • 0.2A • >100,000 • Celsius S36 • Fractal Design Dynamic X2 GP-12 PWM • 500-2000 RPM • LLS bearing • Yes • 32.2 dB(A) • 148.
PAGE 5
P r o d u c t S h e e Additional information Product Code EAN UPC JAN Celsius S24 FD-WCU-CELSIUS-S24-BK 7350041084457 817301014458 4537694237635 Celsius S36 FD-WCU-CELSIUS-S36-BK 7350041084464 817301014465 4537694237645 t
