RL-8221 Mini-USB Organizer User’s Guide www.franklin.
License Agreement READ THIS LICENSE AGREEMENT BEFORE USING THE ELECTRONIC REFERENCE. YOUR USE OF THE ELECTRONIC REFERENCE DEEMS THAT YOU ACCEPT THE TERMS OF THIS LICENSE. IF YOU DO NOT AGREE WITH THESE TERMS, YOU MAY RETURN THIS PACKAGE WITH PURCHASE RECEIPT TO THE DEALER FROM WHICH YOU PURCHASED THE ELECTRONIC REFERENCE AND YOUR PURCHASE PRICE WILL BE REFUNDED. ELECTRONIC REFERENCE means the software product and documentation found in this package and FRANKLIN means Franklin Electronic Publishers, Inc.
Key Guide MODE ENTER When the unit is off, press to turn on the unit. When the unit is on, hold for approximately two seconds to turn off the unit. When the unit is on, press to display the mode icons. From the mode icons, press to scroll through the icons. From the clock, hold for approximately two seconds to enter Edit Mode. From the mode icons, press to select the icon. From the mode icons, press to scroll through the icons. Goes to the Clock. Goes to the World Clock. Goes to the Alarms.
Goes to the Games. PC-LINK RESET Enables the user to change the Language, Memory, Security, Battery, Sound, and Contrast of the unit. Enables the user to transfer data between the unit and a PC. Enables the user to reset the unit. Getting Started 1. Before using the unit, if necessary, gently pull the battery insulation tab to remove it. One 3 volt, CR-2025 lithium battery is preinstalled in the unit. The unit automatically turns on. The prompt RESET? appears. 2. Press ENTER. The prompt SURE? appears. 3.
Replacing the Battery Replace the battery when the unit does not turn on, the display goes blank or the Battery setting in SETUP indicates that the battery is low. You will need a small Phillips screwdriver to replace the battery. Follow these instructions: 1. Make sure the unit is off. 2. Turn the unit over. 3. Unscrew the battery cover screw. 4. Carefully remove the battery cover. 5. If necessary, remove the old battery. 6. Slide a new battery into place under the small prongs with the positive side up.
• • • • Always be sure to load the battery so the positive (+) and negative (-) ends are facing correctly. Never try to charge the battery, take it apart or allow it to become shorted. Keep the battery away from direct flame and heat. Keep the battery out of reach of small children. If swallowed, consult with your physician immediately. Replacing the battery should be done under adult supervision. Setting the Clock 1. From the Home Time, press and hold ENTER until the month field flashes. 2.
Using the Alarms 1. From Alarms, press or to turn on the alarm. 2. To change the time for the alarm, press and hold ENTER until the hour field flashes. 3. Use or to change the hour and press ENTER. 4. Use or to change the minute and press ENTER. Using the Address Book 1. From the Address Book, press ENTER. NAME? appears on the screen. 2. Press or to scroll through letters, numbers and symbols. Press and hold or to scroll quickly. 3.
To view entries already saved, press or . A left arrow flashes next to the first record. Press or to scroll through the entries. Editing Records 1. From the Address Book, press or to view entries already saved. 2. Press or to move the arrow to the entry you want to change. 3. Press and hold ENTER until EDIT flashes on the screen. 4. Press ENTER. 5. Use , and ENTER to change the characters of the entry. To erase a character, select “x”. 6. Press ENTER at a blank cursor to move to the next field.
5. Press ENTER. ERASE? appears on the screen. 6. Press ENTER again to erase the entry. Saving Favorites 1. From Favorites, press ENTER. WEB NAME? appears on the screen. 2. Press or to scroll through letters, numbers and symbols. Press and hold or to scroll quickly. 3. Press ENTER to select the letter, number or symbol that is flashing at the cursor. To erase a character, select “x”. 4. Press ENTER at a blank cursor to move to the next field. You can enter the web address: http://. 5.
Playing Games 1. From Games, press or to move to another game. The available games are SLOT, DICE and LOTTO. 2. Press ENTER to select a game. 3. Press ENTER to play. Changing Settings 1. From the Setup menu, press or to move to another setting. Language enables the user to choose English, Spanish, French, German, Portuguese, Italian or Dutch. Memory displays the percentage of free memory available in the unit. Security enables the user to set a password to protect records stored in the unit.
Note: You cannot change the Memory or Battery settings. For Security, enter the password up to six characters the same way that records are entered. For details, please see “Using the Phonebook”. When the password is set and you turn the unit on and off again, you must enter the password to view Phonebook and Favorites entries. To change the password, enter the existing password and enter a new password. To remove the password, enter the existing password and press ENTER at a blank cursor. 4.
• Available USB port To transfer records from the unit to a PC, follow these instructions. 1. Insert the USB Databank Installation CD into the CD-ROM drive on your PC. 2. The installation screen appears. If the installation screen does not appear, double-click My Computer and then click the drive where you inserted the Installation CD. 3. Follow the instructions on the screen to install the program. 4. Click Finish to complete the installation. The USB Databank software is launched automatically.
If prompted to install the Windows setup disk, insert the Windows setup CD into the CDROM drive. 8. Press the PC-LINK button on the back of the device. Once your PC recognizes the USB Databank, the records from the unit will be transferred to the PC. Graphics appear on the unit to indicate what is happening. Data is being transferred successfully. No data is being transferred between the unit and the PC. Data was transferred successfully.
Specifications Model: RL-8221 Rolodex Mini-USB Organizer • Dimensions: 3.75 x 0.5 x 1.5 in • Battery: 1 CR-2025 lithium • ISBN 1-59074-278-8 FOR HOME OR OFFICE USE © 2004 Franklin Electronic Publishers, Inc. Burlington N.J. 08016-4907 U.S.A. All rights reserved. Care and Maintenance 1. Always keep separate written records of all the important data. 2. Clean the unit with a soft damp cloth and wipe it completely dry. Never clean with a cleaning agent. 3. Do not drop the unit or subject it to strong impact.
FCC Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to insure compliance. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. Limited Warranty (outside U.S.
Limited Warranty (U.S. only) LIMITED WARRANTY, DISCLAIMER OF WARRANTIES AND LIMITED REMEDY (A) LIMITED WARRANTY. FRANKLIN WARRANTS TO THE ORIGINAL END USER THAT FOR A PERIOD OF ONE (1) YEAR FROM THE ORIGINAL DATE OF PURCHASE AS EVIDENCED BY A COPY OF YOUR RECEIPT, YOUR FRANKLIN PRODUCT SHALL BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP. THIS LIMITED WARRANTY DOES NOT INCLUDE DAMAGE DUE TO ACTS OF GOD, ACCIDENT, MISUSE, ABUSE, NEGLIGENCE, MODIFICATION, UNSUITABLE ENVIRONMENT OR IMPROPER MAINTENANCE.
NEITHER FRANKLIN NOR OUR DEALERS OR SUPPLIERS SHALL HAVE ANY LIABILITY TO YOU OR ANY OTHER PERSON OR ENTITY FOR ANY INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, BUT NOT LIMITED TO, LOSS OF REVENUE OR PROFIT, LOST OR DAMAGED DATA OR OTHER COMMERCIAL OR ECONOMIC LOSS, EVEN IF WE HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR THEY ARE OTHERWISE FORESEEABLE. WE ARE ALSO NOT RESPONSIBLE FOR CLAIMS BY A THIRD PARTY.
NAL DATE OF PURCHASE. YOU MUST ALSO WRITE THE RMA PROMINENTLY ON THE PACKAGE IF YOU RETURN THE PRODUCT, OTHERWISE THERE MAY BE A LENGTHY DELAY IN THE PROCESSING OF YOUR RETURN. WE STRONGLY RECOMMEND USING A TRACKABLE FORM OF DELIVERY TO FRANKLIN FOR YOUR RETURN. This unit may change operating modes due to electro-static discharge. Normal operation of this unit can be re-established by pressing MODE, or by removing/replacing the battery. RMB-28000-00 Rev.
