Individual Request Type Descriptions
unsigned char *cryptDataOut;
unsigned long hashDataOutBytes;
unsigned char *hashDataOut;
unsigned long cryptCtxOutBytes;
unsigned char *cryptCtxOutData;
NUM_IPSEC_ESP_DESC defines the number of descriptors within the DPD_IPSEC_ESP_GROUP that use this
request.
DPD_IPSEC_ESP_GROUP (0x7500) defines the group for all descriptors within this request.
Table 28. IPSEC_ESP_REQ Valid Descriptors (opId)
Descriptors Value Function Description
DPD_IPSEC_ESP_OUT_SDES_ECB_CRPT_MD5_PAD 0x7500 Process an outbound IPSec encapsulated system
payload packet using single DES in ECB mode and
MD5 with auto padding
DPD_IPSEC_ESP_OUT_SDES_ECB_CRPT_SHA_PAD 0x7501 Process an outbound IPSec encapsulated system
payload packet using single DES in ECB mode, and
SHA1 with auto padding
DPD_IPSEC_ESP_OUT_SDES_ECB_CRPT_SHA256_
PAD
0x7502 Process an outbound IPSec encapsulated system
payload packet using single DES in ECB mode, and
SHA256 with auto padding
DPD_IPSEC_ESP_IN_SDES_ECB_DCRPT_MD5_PAD 0x7503 Process an inbound IPSec encapsulated system
payload packet using single DES in ECB mode, and
MD5 with auto padding
DPD_IPSEC_ESP_IN_SDES_ECB_DCRPT_SHA_PAD 0x7504 Process an inbound IPSec encapsulated system
payload packet using single DES in ECB mode, and
SHA1 with auto padding
DPD_IPSEC_ESP_IN_SDES_ECB_DCRPT_SHA256_
PAD
0x7505 Process an inbound IPSec encapsulated system
payload packet using single DES in ECB mode, and
SHA256 with auto padding
DPD_IPSEC_ESP_OUT_SDES_CBC_CRPT_MD5_PAD 0x7506 Process an outbound IPSec encapsulated system
payload packet using single DES in CBC mode, and
MD5 with auto padding
DPD_IPSEC_ESP_OUT_SDES_CBC_CRPT_SHA_PAD 0x7507 Process an outbound IPSec encapsulated system
payload packet using single DES in CBC mode, and
SHA1 with auto padding
DPD_IPSEC_ESP_OUT_SDES_CBC_CRPT_SHA256_
PAD
0x7508 Process an outbound IPSec encapsulated system
payload packet using single DES in CBC mode, and
SHA256 with auto padding
DPD_IPSEC_ESP_IN_SDES_CBC_DCRPT_MD5_PAD 0x7509 Process an inbound IPSec encapsulated system
payload packet using single DES in CBC mode, and
MD5 with auto padding
