Installation Guide

11
1 OVERVIEW
Low Voltage
Battery
Battery Management
System
Cellular Modem
Computer Processor
Circuit Breakers
1 2 3 4 5 6 9
8
Breaker Function
1 Main AC contactor
2 AC/DC battery charger 1
3 AC/DC battery charger 2
4 Battery air conditioning
5 Liquid cooling system pump
6 24 V system power supply
8 Computer processor power
9 Battery heaters
Located on the upper
low-voltage shelf
