3 BOOST CHARGER SPECIFICATIONS
3 Boost Charger Specifications
System
Max Output Power
CHAdeMO: 100 kW
CCS: 120 kW
Combined: charge two vehicles up to 60 kW each
Max Output Current
CHAdeMO: 200 A
CCS: 300 A
Dimensions 40 in x 43 in x 96 in
Weight 3,800 lbs
Output Voltage, Charging 200 VDC – 500 VDC
Supported Connector Types
CCS1 (SAE J1772™ Combo)
CHAdeMO
Charge Cable Length 140 in
User Interaction Display Full-color 24-inch LCD display for driver interaction
Authentication RFID: ISO 15693, ISO 14443, NFC
Input Rating
240 (+/- 10%) VAC, split-phase, 4-Wire, 120 A, 60 Hz
208 (+/- 10%) VAC 3-phase, WYE, 5-Wire, 80 A 60 Hz
Wiring
For 240 V - 2 conductors (L1, L2) Ground
For 208 V - 4 conductors (L1, L2, L3, Neutral) Ground
Required Service Panel Breaker
150 A 240 V
100 A 208 V
Electrical Input
Interfaces
