® This appliance can be used by children 8 years and above and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervisor instruction concerning use of the appliance in a safe way and understand the hazards involved. © Children shall not play with the appliance. o Cleaning and user maintenance shall not be made by children without supervision. * Do not operate your air conditioner in a wet room such as a bathroom or laundry room.
Correctly dispose of the product at the end of its working life. Do not send to urban waste but use a specialized waste collection center or a dealer providing this service. Correct disposal allows recycling, conserving energy and resources and avoids negative consequences to the environment and health. Refer to crossed out wheeled dustbin symbol as a reminder. ELECTRICAL CONNECTIONS # Failure to follow these important safety instructions absolves all liability for the manufacturer.
Improper handling can cause serious damage to the appliance. Read this manual carefully before operating the unit. Do not wet the housing or Do not cover the air outset Do not allow children to control panel. while in use. play with the controls or o drop any objects into the g & air outlet. = Do not place objects or let Always turn the unit off Do not attempt to remove any person sit on top of and remove the power any part of the casing the unit. plug from the socket when unless by an authorized cleaning.
Identification of parts 1. Control panel Air outlet Handle hole Caster Air outlet ( Heat exchange ) Air intake ( Evaporator ) Air intake ( Condenser Alr filter Water outlet drain for continuous drain operation ( Dehumidify mode only ) 5 10. Water outlet drain (Note: Please ensure that the water ? outlet drain is properly installed before use.) 11. Power supply cord 12.
CONTROL PANEL Naming Light Timer / Temp. Set Controls Fan Speed Control Power Control The power control turns the unit on and off. Warning Light A Condensed water may accumulate in the unit. If the internal tank becomes full, the Naming Light will shine and the unit will not operate until the unit has been drained. Mode Control The Mode Control has 4 settings: « Cool s Dehumidify «Fan -Heating The settings are adjusted with Mode Control button. A light will indicate which sifting is currently belong used.
Air Conditioner Remote Control The functions work the same as your air conditioner's touch controls. All key functions can be accessed from the remote control. CONTROL PANEL Mode Control Press this button to change the operation mode in the order of : —> Dehumidify Heat Fan @Supermodel only) Power Control MODE On/ Off Timer Control TIMER In running mode : OFF/ON Auto switch off In stand-by mode : Auto switch on Press button to adjust the time setting for 1 hour interval.
3.Insert the window panels B and C to each end of main panel A. Adjusting to fix the length of window panels by using the screws and nuts mounted on the 2 ends of main panel A. 1OE01 A B C 4.0pen the window and place window panels into window. Adjust the extension panels to fit width or height of window by the screw and nut sets mounted on the main panel A. ~® INDOOR INDOOR 5.Insert the other end of exhaust hose assembly {with hose connector #3) onto window bracket. 6.
Built-In Drain Pump (ZHP14DA model only) The condensate produced in heating mode can also be drained through the supplied drain hose utilizing the internal built-in drain pump. Follow the steps below for proper operation of the pump. NOTE : The built in drain pump can be used in all modes. Installation: (See Figures 1&2) STEP 1. Connect the supplied drain hose to the drain key. STEP 2. Connect the drain key and hose to the drain outlet located on the rear panel. STEP 3.
10 Appliance maintenance O Cut off the power supply 0 w Tum off the appliance g first before disconnecting from power supply Air filter maintenance It is necessary to clean the air filter after using it for about 100 hours. Clean it as follows: 9 Wipe with a soft dry cloth. If unit is quite dirty use a mild detergent and damp cloth. Never use volatile substance such as gasoline or polishing powder to clean the appliance. Stop the appliance and remove the air filter.
® Figures noted, in the contents are for reference only; variation may result due to application in different countries or regions, and shall be based on the best of practical operation. Heat Pump Portable ) Description of product | Portable Air Conditioner Air Conditioner Model ZCP12DA ZHP14DA Voltage/Frequency AC 115V ~ 60Hz AC 115V ~ 60Hz Current Consumption 98A 114A Coolant R-410A R-410A Timer 24 hour 24 hour e D) 447 XTATx405mm | 447 x 747 x 405 mm Weight 30.
