All about the Use & Care of your Room Air Conditioner TA B L E O F C O N T E N T S Important Safety Instructions ............................... 2-3 Operating Instructions ......................................... 5-10 Product Registration ............................................. 4 Care and Cleaning .............................................. 11 Packaging ........................................................... 4 Energy Saving Ideas ...........................................
Important Safety Instructions NOTE: This USE & CARE MANUAL provides specific operating instructions for your model. Use the room air conditioner only as instructed in this USE & CARE MANUAL. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating, and maintaining any appliance.
Important Safety Instructions SAFETY PRECAUTIONS CAUTION! Avoid Injury or damage to the unit or other property Provide occasional ventilation during use. Do not direct airflow at fireplaces or other heat related sources as this could cause flare ups or make units run excessively. Do not climb on or place objects on outdoor part of the unit. Do not hang objects off the unit. Do not place containers with liquids on the unit.
Product Registration, Packaging & Normal Sounds Product Registration Record Your Model and Serial Numbers Record in the space provided below the model and serial numbers. On all models, the serial plate is located on the outside of the cabinet. Model No. Serial No. Register Your Product The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to the Frigidaire Company.
Air Conditioner Features & Operating Instructions Air Conditioner Features ELECTRONIC CONTROL Before you begin, thoroughly familiarize yourself with the control panel and remote as shown below and all its functions, then follow the symbol for the functions you desire. The unit can be controlled by the touch pad alone or with the remote.
Operating Instructions Operating Instructions (continued) TO CHANGE TEMPERATURE SETTlNG: DO THIS: PRESS TO RAISE PRESS TO LOWER TO ADJUST FAN SPEEDS: YOU WILL SEE: Note: Tap or hold either up ( ) or down ( ) button until the desired temperature is seen on the display. This temperature will be automatically maintained anywhere between 60 °F (16 °C) and 90 °F (32 °C) . If you want the display to read the actual room temperature. See "To Operate on Fan Only" section on Page 7.
Operating Instructions Operating Instructions (continued) TO OPERATE ON FAN ONLY: DO THIS: PRESS MODE BUTTON CHOOSE FAN ONLY YOU WILL SEE: Note: Use this function only when cooling is not desired, such as for room air circulation or to exhaust stale air on some models. (Remember to open the vent during this function, but keep it closed during cooling for maximum cooling efficiency.) You can choose any fan speed you prefer. (Except “Auto Fan”).
Operating Instructions Operating Instructions (continued) TIMER: DELAY STOP / START FEATURE YOU WILL SEE HOW MUCH TIME IS CHOSEN: THEN DO THIS: FIRST DO THIS: PRESS TIMER BUTTON PRESS UP/DOWN BUTTONS Note: For Delay Stop, the unit must be in the On position． Note: For Delay Start, the unit must be in the Off position. First, Press TIMER button, then adjust timer setting, tap or hold the UP arrow ( ) or the DOWN arrow ( ) to change delay timer at 0.
Operating Instructions Operating Instructions (continued) REMOTE SENSING FEATURE (on some models)： LIGHT pulsing ( On & Off intermittently ). DO THIS: PRESS REMOTE SENSING START BUTTON NOTE: Unit display shows the set temperature NOTE: Remote display is actual temperature at remote control only Note: This feature can be activated from the remote control ONLY, the unit must be in a cooling mode.
Operating Instructions Operating Instructions (continued) TO TURN UNIT OFF: YOU WILL SEE: Note: If the unit is turned off in heat mode (if applicable) or fan only mode, it will return to the same setting when it is turned on again. When the unit is turned off in cool or energy saver(econ) mode, it will run in energy saver(econ) mode when it is turned on again, but the setting of temperature and fan speed will remain.
Care and Cleaning & Energy Saving Ideas Care and Cleaning Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils. Push the vent handle to the Vent Closed position(where applicable). Open the front panel.
Before You Call Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. OCCURRENCE SOLUTION Air conditioner will not operate. Wall plug disconnected. Push plug firmly into wall outlet. Plug Current Device Tripped. Press the RESET button. House fuse blown or circuit breaker tripped. Replace fuse with time delay type or reset circuit breaker. Control is OFF.
Major Appliance Limited Warranty Your appliance is covered by a limited one-year warranty and a limited 2-5 year warranty on the sealed system (the compressor, condenser, evaporator and tubing). For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
