17BC.SpecSheet

The Pasta Magic® electric cookers incorporate
all the features the industry has been looking
for in a pasta cooker. Electronic, programmable
controls make it easy to cook perfect pasta
exactly as desired every time and do it all
automatically and reliably. The electric cookers
feature Frymaster’s exclusive smooth-surfaced,
easy-clean, touch-pad timer/controller and
because it’s electric it can be installed without
hood venting in many markets.
The units are available in 8 kw or 17 kw of
power, meaning faster preheat and recovery
performance, which saves time and allows the
operator to turn pasta orders faster.
To prevent boil-overs, the cookpot has the
industry’s largest overflow drain.This drain
carries away any excess water that might be
added to the cookpot and starch that might
accumulate with repeated cooks. This large
drain also reduces the time needed to drain the
system and virtually eliminates the chance of
clogs, which is common in pasta cookers with
smaller drain openings.
An auto-fill/starch skimmer keeps the water
level at the correct height and removes excess
starch residue from the water’s surface. There is
no need for refills, so the water is ready to cook,
saving energy and time.
Frymaster’s automatic timer and basket lift
features ensure precise cook times without
constant monitoring.
Specifications
Standard Features
8SMS
8BC
8C
17SMS
17BC
17C
Models
Electric Cookers
Pasta Magic Electric Cookers
Project
Item
Quantity
CSI Section 11400
Approval
Date
8700 Line Avenue
Shreveport, LA 71106-6800
USA
Tel: [phone]
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.frymaster.com
Bulletin No. 818-0643
Revised 3/17/15
Options & Accessories
• Programmable timer controller
• Large overflow drain
• 1-1/4” (3.2 cm) drain valve
• Auto-fill/starch skimmer
• Swing-away hot/cold rinse faucet
• Stainless steel cookpot, door and cabinet
• 6” (15.2 cm) steel legs with 1” adjustment
•Automatic timed basket lift (8SMS, 8BC,
17SMS and 17BC)
Casters
Round pasta baskets (3 per
bundle)
Rinse tank screen
Shown with optional casters
8 kw Models
• 8 kw incoloy heating element
ensures fast preheat and recoveries
• 8-3/4 gallon (33.1 liter) water capacity
• 16” x 18-3/4” x 6-1/4” (40.6 x 47 x 16
cm) cooking area
• Handle max load of 3 lbs. of dry
pasta
• 9-cup portion cup rack with 18
portion cups
• Bulk pasta basket
17 kw Models
• 17 kw incoloy heating element
ensures fast preheat and recoveries
• 19-1/2 gallon (73.8 liter) water
capacity
• 18” x 24” x 8-3/4” (45.7 x 61 x 22.2
cm) cooking area
• Handle max load of 5 lbs. of dry
pasta
• 12-cup portion cup rack with 24
portion cups
• Bulk pasta basket
CE Approval for
8SMS/8BC/8C only.
TM
