User's Manual
7-7
Trouble-
shooting
TROUBLE-SHOOTING
Operating Problems
If any of the errors listed in Table 7.3 occurs, the PAPER OUT LED lights
up, and an alarm beeps, and the printer goes offline.
In such cases, the buttons on the control panel can be used in the same
manner as those when the printer is in the offline state.
Table 7.3 Operating Problems and Solutions
Paper end (PE) error
Paper end is detected.
(*1)
-
Insert and load the
paper in the paper tray.
Eject jam error
Paper end is not detected
- Eject forms or sheets.
even after a large amount
- Press the online button
of continuous forms or cut
to turn the printer online.
sheets were ejected.
Continuous form/
In continuous form loading
- Switch the continuous
cut sheet switch status, the continuous form/
form/cut sheet switch
lever
error cut sheet switch lever is
lever back to its original
switched to cut sheet mode.
position.
In cut sheet loading status,
- Remove the loaded
the continuous form/cut
paper.
sheet switch lever is switched
to continuous form mode.
If the error occurs, all
buttons are disabled.
Load jam error
After the tractor PE sensor
- Execute the loading
detected the form at continuous
operation.
form loading, the TOF sensor
- Press the online button
does not detect the top of the
to turn the printer
form even after line feed is
online.
executed a certain number of - When the cut sheets are
times.
loaded, remove the
After the set sensor detects the
sheets once, and
sheet at cut sheet
then insert them again.
loading, the TOF sensor
They are then loaded
does not detect
he top of
automatically.
the sheet even after line
feed is executed a certain
number of times.
Error name Error description Recovery method
