IR Keyboard.fm Page 1 Wednesday, March 3, 2004 1:25 PM F u j i t s u C o m p u t e r S y s t e m s Wireless Keyboard with Touch Pad, User’s Guide FPCKB51A1P I N S T R U C T I O N S The wireless keyboard allows you to enter data into your Tablet PC without the clutter and constraints of cables. Before using the wireless keyboard, you should read through this manual to become familiar with the keyboard.
IR Keyboard.fm Page 2 Wednesday, March 3, 2004 1:25 PM Installing the Keyboard Batteries Before installing or replacing the batteries in your wireless keyboard, be sure to note the following: • Ensure that the correct polarities (+ and -) are used when installing new batteries in the keyboard. • Don’t mix old and new batteries. • If the keyboard won’t be used for a long period, remove the batteries to prevent electrolyte leakage.
IR Keyboard.fm Page 3 Wednesday, March 3, 2004 1:25 PM Foot Battery Compartment Cover Foot Figure 1. Bottom of wireless keyboard Installing the Keyboard Driver Before using the wireless keyboard, you will need to install a new keyboard driver. There are two ways to install the new driver: Wireless Keyboard Driver CD The Wireless Keyboard Driver CD is included with the wireless keyboard.
IR Keyboard.fm Page 4 Wednesday, March 3, 2004 1:25 PM To install the driver from an external drive: 1. Attach the drive to the tablet. 2. Turn on the system. 3. Open the drive and insert the CD. The system will automatically recognize the CD and begin the installation. Follow the instructions that appear to install the driver. 4. When finished, remove the CD. Fujitsu Web Site The driver can be downloaded from the Fujitsu Web site. TO download the driver: 1. Log onto the Internet. 2.
IR Keyboard.fm Page 5 Wednesday, March 3, 2004 1:25 PM ■ ■ Don’t attempt to use a wireless keyboard at the same time as a wired keyboard. Wired keyboards takes precedence over wireless, so the wireless keyboard becomes disabled. If a key on the keyboard is depressed continuously, the battery will automatically shut off after approximately 60 seconds to preserve battery life. Power/Suspend/Resume button Left button Infrared Transmitter Right button Scroll button Touchpad Figure 2.
IR Keyboard.fm Page 6 Wednesday, March 3, 2004 1:25 PM Keyboard Features On/Off Switch The On/Off switch is located on the top edge of the keyboard. It is used to power the keyboard on and off. The keyboard should be powered off when it is not used for extended periods in order to maximize battery life. Power/Suspend/Resume Button The Power/Suspend/Resume button on the keyboard works in the same manner as the power/suspend/resume button on the computer.
IR Keyboard.fm Page 7 Wednesday, March 3, 2004 1:25 PM move the mouse cursor to the item you wish to select, press the right button once, and then immediately release it. You can also perform the clicking operation by tapping lightly on the Touchpad once. (Figure 4) Figure 4. Clicking Double-Clicking Double-clicking means pushing and releasing the left button twice in rapid succession. This procedure does not function with the right button.
IR Keyboard.fm Page 8 Wednesday, March 3, 2004 1:25 PM ■ ■ If the interval between clicks is too long, the double-click will not be executed. Parameters for the Touchpad can be adjusted from the Mouse Properties dialog box located in the Windows Control Panel. Dragging Dragging means pressing and holding the left button, while moving the cursor. To drag, move the cursor to the item you wish to move. Press and hold the left button while moving the item to its new location and then release it.
IR Keyboard.fm Page 9 Wednesday, March 3, 2004 1:25 PM bottom of the button to scroll up or down a page. When you have reached the desired section of the page, release the button. (Figure 7) Figure 7. Scrolling Keyboard Layout Your computer has an integral 86-key keyboard. The keys perform all the standard functions of a 101-key keyboard, including the Windows keys and other special function keys. This section describes the following keys.
IR Keyboard.fm Page 10 Wednesday, March 3, 2004 1:25 PM or division ( / ), and enter decimal points ( . ) using the keys designated as ten-key function keys. The keys in the numeric keypad are marked on the front edge of the key to indicate their secondary functions. Function Keys Fn Key Start Key Numeric Keypad Cursor Keys (surrounded by black line) Application Key Figure 8. Key Layout Windows Keys Your keyboard has two Windows keys, consisting of one Start key and one Application key.
IR Keyboard.fm Page 11 Wednesday, March 3, 2004 1:25 PM Cursor Keys The cursor keys are the four arrow keys on the keyboard which allow you to move the cursor up, down, left and right in applications. In programs such as Windows Explorer, it moves the “focus” (selects the next item up, down, left, or right). Function Keys The keyboard has 12 function keys, F1 through F12. The functions assigned to these keys differ for each application.
IR Keyboard.fm Page 12 Wednesday, March 3, 2004 1:25 PM Each time you press the combination of keys you will step to the next choice. The choices, in order, are: built-in display panel only, both built-in display panel and external monitor or external monitor only. Overview of Identification Codes When multiple keyboards and computers are used in a small area, it may be necessary to assign an individual identification code to each keyboard/Tablet PC pair.
IR Keyboard.fm Page 13 Wednesday, March 3, 2004 1:25 PM assign keyboard A the identification code “1” and keyboard B the identification code “2”, then use keyboard B first, the Tablet PC will only recognize the keyboard B identification code “2”.
IR Keyboard.fm Page 14 Wednesday, March 3, 2004 1:25 PM Troubleshooting the Wireless Keyboard The wireless keyboard is used in the same way as a normal wired keyboard. In typical operation, you should encounter few problems in transmitting data to your Tablet PC. If your keyboard fails to perform properly, check for the following circumstances: 14 ■ The identification code has been changed inadvertently.
IR Keyboard.fm Page 15 Wednesday, March 3, 2004 1:25 PM Caring for your keyboard Your wireless keyboard is a durable but sensitive electronic device. ■ ■ ■ ■ ■ If you accidentally spill liquid on your keyboard, position it so that the liquid can run out, then let it dry out for 24 hours, or longer, as required. Do not use your keyboard in a wet environment (near a bathtub, swimming pool). Avoid exposure to sand, dust and other environmental hazards. Do not put heavy or sharp objects on the keyboard.
IR Keyboard.fm Page 16 Wednesday, March 3, 2004 1:25 PM Wireless Keyboard Specifications Hardware Specifications Interface Infrared, simplex serial No. of Keys 86 keys Stroke 3.0mm + 0.5mm Key Pitch 19.05mm (typical) Dimensions Width: 12.44” (316 mm) Depth: 8.66” (220 mm) Height: 0.57” - 0.76” (14.5 - 19.2 mm) Approximate Weight 1.3 lbs. (0.
IR Keyboard.fm Page 17 Wednesday, March 3, 2004 1:25 PM DECLARATION OF CONFORMITY according to FCC Part 15 Responsible Party Name: Fujitsu Computer Systems Corporation Address: 1250 E. Arques Avenue, M/S 122 Sunnyvale, CA 94085 Telephone: (408) 746-6000 Declares that product: Wireless Keyboard with Touchpad Model FPCKB51A1P Complies with Part 15 of the FCC Rules. This device complies with Part 15 of the FCC rules.
IR Keyboard.fm Page 18 Wednesday, March 3, 2004 1:25 PM FCC Notices Notice to Users of Radios and Television These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
IR Keyboard.
IR Keyboard.fm Page 20 Wednesday, March 3, 2004 1:25 PM Fujitsu Computer Systems Corporation 1250 E. Arques Avenue (M/S 122), Sunnyvale, California 94085 For more information, call 1-877-372-3473 or visit our Web site at: us.fujitsu.com/computers For technical support call: 1-800-8Fujitsu (1-800-838-5487) or e-mail us at: 8fujitsu@us.fujitsu.com Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu, Ltd. All other trademarks mentioned herein are the property of their respective owners.
