Activating the Test Mode
To activate the test mode:
1. Turning power on with
MENU
pressed.
The LCD indicates “Please wait” then “<<MODE
SELECT>>” with “SETUP” blinking.
2. Press twice.
“TEST” blinks (blinking indicates “selectable).
3. Press
ENTER
.
The <<TEST MODE>> initial screen (*) appears.
4. Press
ENTER
.
The <<TEST MODE>> menu screen (**) appears.
To quit the test mode, turn power off.
<<TEST MODE>>
* <<TEST MODE>> Initial screen
T Please wait
<<MODE SELECT>>
SETUP BROWSE TEST
<<MODE SELECT>>
SETUP BROWSE TEST
<<TEST MODE>>
Offline Feed Test
** <<TEST MODE>> menu screen
Button functions in test mode
Button name Function
Returns to the <<TEST MODE>> menu screen.
• Executes the test.
• Returns to the previous screen.
• Displays the next lower level screen.
Returns to the previous screen without saving the change.
• Displays the next function at the right in the menu.
• Moves to the right item.
• Displays the next test function at the left in the menu.
• Moves to the left item.
Scrolls the option downward.
Scrolls the option upward.
MENU
ENTER
CANCEL
