Computer Products of America Image Scanner Operator's Guide fi-4990C

1-3
No. Name Function
1 Operator panel Used to operate the scanner.
2 Power switch Used to power on or off.
3 Hopper Document input tray.
4 Hopper guides Used to adjust the document width.
5 Hopper extension For use with long documents.
6 Automatic document feeder (ADF) Feeds documents automatically.
7 ADF release lever Used to open the ADF.
8 Pick roller unit Picks top page in document stack.
9 Guide plate The pad unit is mounted on.
10 Pad Separates top page from document stack.
11 Brake roller Separates top page from document stack.
12 Upper transport unit Opens for easy access.
13 Lever Used to open the upper transport unit.
14 Side cover Opens to access back-side lamp.
15 Stacker Document exit tray.
16 Check stopper Adjustable stopper for shorter length documents.
17 Stacker guides Helps guide documents into stacker.
18 Stop lever Used to keep documents in the stacker.
19 Stacker extension For use with long documents.
20 Main line switch Controls supply of line power to the scanner.
21 Power inlet Power cable connection.
22 Interface connectors Ultra Wide SCSI (1pcs.)
