Computer Products of America Image Scanner Operator's Guide fi-4990C

1-7
Operation status display
After power is turned on, the LCD indicates the following messages in normal mode.
Please wait Wait for a moment. This is indicated when processing takes a long
time.
When this is displayed after turning power on, the second line
indicates initializing messages.
Ready The scanner can receive a command from the host computer or
can be set in setup, browse, or test mode.
Manual Feeding Load documents on the hopper table manually.
Feeding The scanner is feeding documents. The second line indicates the
number of documents fed per batch.
Error status display
When the scanner detects errors, the LCD indicates the following messages. There are two types of
errors: temporary errors and equipment errors.
Temporary errors (Ex.): The message is cleared just by following the next message.
Hopper empty Mis-pick Cover open
Equipment errors (Ex.): To clear the message, you must clean or replace the specified part.
Optical error: Front Optical error: Back
