4-2
Document Quality
This section describes paper types of documents and ream weights of paper available for the scan-
ner, and precautions.
Paper types of documents
The recommended paper types of documents are as follows:
NOTE
Please use the specified paper. (In rare occasion, double feeding or document damage may occur.)
• Fine paper
• Plain paper
• OCR paper
When using any other paper types of documents, place a test batch of documents in to the ADF to
see if it successfully feeds the documents.
NOTE
Documents may be damaged when an error occurs.
Ream weight of paper
The ream weight of paper is as follows:
• 52 to 127 g/m
2
(13.9 to 34 lb)
NOTE
