6-1
Setup, Browse, and Test Modes
This scanner has the setup mode, browse mode, and test mode to ease setting up.
• Setup mode for customizing the scanner for user requirements
• Browse mode for glancing setup conditions of the scanner
• Test mode for testing the scanner offline
There are two ways to enter these modes:
• Way 1
Press
MENU
when the LCD indicates “Ready”.
You can use the setup mode and browse mode. To quit a mode, press
CANCEL
.
• Way 2
Turn the power on while pressing
MENU
.
You can use the test mode in addition to the setup mode and browse mode. To quit a mode, turn
off the power.
Available functions differ with modes or with ways. For details, see descriptions of each function.
Functions not available in setup mode
Way Functions not available
MENU
pressed in Ready status TP_IF baud rate, SCSI ID, Product ID, Function key, Setup mode lock
Functions not available in browse mode
Functions not available
Paper thickness setup
