6-5
Remarks
Displayed in setup mode selected by turning
power on with
MENU
pressed.
Displayed in setup mode selected by turning
power on with
MENU
pressed.
Displayed in setup mode selected by turning
power on with
MENU
pressed.
Displayed in setup mode selected by turning
power on with
MENU
pressed.
• Displayed in setup mode selected by turning
power on with
MENU
pressed.
• Setup functions allocated to
F1
,
F2
,
and
F3
buttons are always valid
regardless of this setting.
Displayed in setup mode selected by turning
power on with
MENU
pressed.
Displayed in setup mode selected by turning
power on with
MENU
pressed.
Displayed in setup mode selected by turning
power on with
MENU
pressed.
The details and the operation method, please
refer to the “M4099D/M4099DC/fi-4990/fi-4990C
Image Scanner Operator’s Guide : Option”.
Setup item
TP_IF baud rate
SCSI ID
Product ID
Pre-pick
Pick start time
Manual feed timeout
Paper pick retry
Paper feed retry
Function key
Setup mode lock
Language
White follower mode
Interface Board slot
SCSI Bus Width setting
* Printing Position
Description
Selects the control data transfer rate (2400,
4800, 9600, or 19200) for the TP interface.
Sets the SCSI ID of this scanner.
Sets the product ID of this scanner.
Enables or disables pre-picking.
Sets the period from when paper is loaded
manually to when the pick operation starts.
Sets the waiting period from when the host
computer issues a scan command to when
paper is loaded manually.
Sets the pick motor operation time and retry
count.
Sets the feed motor operation time and retry
count.
Allocates setup functions to
F1
,
F2
,
and
F3
buttons.
Inhibits the operator panel from entering
setup mode from normal mode.
Select the Operation Panel LCD display
language (Japanese/English).
Selects the white Level follower operation “0”
means default “1”means operate like
M3099X scanner.
Selects the Interface Board Slot “1” or “2”.
When connects Narrow SCSI card, Selects
“8 bit”.
Set the Endorser print start position.
* If the option is not mounted, the set up item for the option does not display on the screen and skips
to the next item.
13C6.P65 01.2.17, 5:46 PM5
