6-11
<<SETUP MODE>>
Paper Thickness Setup
Ready
Paper Thickness Setup
Adjusting!!
Finished!!
5. Press
ENTER
.
The “Adjusting!!” message appears. The scanner
lifts the hopper, feeds the paper, adjusts the
sensing level of the sensor, and saves its value.
After adjustment, the sheet is ejected and the
“Finished!!” message appears for two seconds,
then the LCD returns to the <<SETUP MODE>>
menu screen (Paper Thickness Setup).
If an error (for example, Mis-pick) occurs during
adjustment, remove the paper and press
CANCEL
. The paper load prompting screen
appears again. Repeat steps 4 and 5.
6. Press
CANCEL
two times.
The LCD returns to the Ready screen.
13C6.P65 01.2.17, 5:46 PM11
