6-13
IPC-3 Mode
0
IPC-3 Mode
5
IPC-3 mode
This function selects a pattern to be set in the IPC-3 image processing feature.
Remarks
0: do not select any pattern
1 to 5: select pattern numbers 1 to 5
LCD display
IPC-3 Mode
Options
0, 1, 2, 3, 4, 5 (Default : 0)
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press four times.
The <<SETUP MODE>> menu screen (IPC-3
Mode) appears.
3. Press
ENTER
.
The option select screen appears with the
current setting 0 blinking (blinking indicates
“changeable”).
4. Press or .
The displayed option changes (1, 2, 3, 4, 5).
5. When the desired pattern number appears,
press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (IPC-3 Mode).
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
IPC-3 Mode
The following is an example of operation when you use this function.
<<SETUP MODE>>
IPC-3 Mode
