6-22
Consumable counter
This function displays or sets a value of the counter which informs the user of the life (replacement
cycle) of a consumable. When the number of sheets fed reaches the set value, an alarm occurs. Set
this value according to types of paper you use. When using fine paper, the standard replacement
cycle of pick roller units, brake rollers, and pads is per three hundred thousands of sheets fed. So,
we recommend you to set the value to 0300000.
Remarks
This setting can be changed in ten
thousands of sheets. The least four
digits of zeros are automatically
added.
LCD display
Consumable Counter
Options
10000 to 2560000 sheets
(Default: 2560000 sheets)
The following is an example of operation when you use this function.
Background Changeover
F: White B: White
4. Press .
White (current option for Back) blinks (blinking
indicates “changeable”).
5. Press or .
The displayed option changes (Black).
6. Press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (Background Changeover).
7. Press
CANCEL
two times.
The LCD returns to the Ready screen.
<<SETUP MODE>>
Background Changeover
Ready
Background Changeover
F: White B: Black
