6-27
Buzzer
This function enables or disables the buzzer sound when an error occurs.
NOTE
The buzzer sounds regardless of this setting when use this function.
RemarksLCD display
Buzzer
Options
On, Off (Default: Off)
The following is an example of operation when you use this function.
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “Buzzer” appears
in the lower line of the menu screen.
3. Press
ENTER
.
The option select screen appears with the
current setting OFF blinking (blinking indicates
“changeable”).
4. Press or .
The displayed option changes (ON blinks).
5. Press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (Buzzer).
6. Press
CANCEL
two times.
The LCD returns to the Ready screen.
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
Buzzer
Buzzer
OFF
Buzzer
ON
<<SETUP MODE>>
Buzzer
Ready
