6-28
Buzzer Volume
Min n n n q q q Max
Buzzer volume
This function sets the sound volume of the buzzer in seven steps.
NOTE
This setting is valid both for occurrence of an error and for press of an operator panel button.
Remarks
Minimum
to (seven steps)
Maximum
LCD display
Buzzer Volume
Options
q q q q q q
to (Default: n n q q q q)
n n n n n n
* Symbols of volume may differ from the actual symbols used in the LCD.
The following is an example of operation when you use this function.
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “Buzzer Volume”
appears in the lower line of the menu screen.
3. Press
ENTER
.
The option select screen appears with the
current setting n n q q q q (no blinking but
changeable).
4. Press or .
The displayed option changes (n n n q q q
to n n n n n n, q q q q q q or n q q q q
q).
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
Buzzer Volume
Buzzer Volume
Min n n q q q q Max
