6-29
5. When the desired option appears, press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (Buzzer Volume).
6. Press
CANCEL
two times.
The LCD returns to the Ready screen.
<<SETUP MODE>>
Buzzer Volume
Ready
LCD contrast
This function sets the contrast of the LCD on the operator panel in seven steps.
Remarks
Dark (low contrast)
to (seven steps)
Bright (high contrast)
LCD display
LCD Contrast
Options
q q q q q q
to (Default: n n q q q q)
n n n n n n
* Symbols of volume may differ from the actual symbols used in the LCD.
The following is an example of operation when you use this function.
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “LCD Contrast”
appears in the lower line of the menu screen.
3. Press
ENTER
.
The option select screen appears with the
current setting n n q q q q (no blinking but
changeable).
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
LCD Contrast
LCD Contrast
Dark n n q q q q Bright
