SCSI ID
This function sets the ID number for the SCSI interface.
NOTE
You cannot use this function when the setup mode is brought by pressing
MENU
in the Ready
status.
RemarksLCD display
SCSI ID
Options
0 to 7 (Default: 5)
The following is an example of operation when you use this function.
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “SCSI ID” appears in
the lower line of the menu screen.
3. Press
ENTER
.
The option select screen appears with the current
setting 5 blinking (blinking indicates “change-
able”).
4. Press or .
The displayed option changes (6, 7, 0, 1, 2, 3, 4).
5. When the desired value appears, press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (SCSI ID).
6. To quit the <<SETUP MODE>>, turn off the
power.
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
SCSI ID
3
<<SETUP MODE>>
SCSI ID
SCSI ID
5
<<SETUP MODE>>
SCSI ID
