6-38
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “Paper Pick retry”
appears in the lower line of the menu screen.
3. Press
ENTER
.
The option select screen appears with the
current setting 2 (for Step) blinking (blinking
indicates “changeable”).
4. Press .
The current count setting 4 blinks.
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
Paper Pick retry
Paper Pick retry
Step: 2 Times: 4
Paper Pick retry
Step: 2 Times: 4
6. Press
CANCEL
two times.
The LCD returns to the Ready screen.
Ready
Paper pick retry
This function sets the pick motor rotation period and the retry count.
Remarks
1 to 7: one time to seven times the standard
steps
1 to 7: one retry to seven retries
LCD display
Paper Pick retry
Options
Step: 1 to 7 (Default: 2)
Times: 1 to 7 (Default: 4)
The following is an example of operation when you use this function.
15C6.P65 01.2.17, 5:47 PM38
