6-39
<<SETUP MODE>>
Paper Pick retry
Ready
Paper Pick retry
Step: 2 Times: 7
5. Press or .
The displayed option changes (1, 2, 3, 4, 5, 6,
7).
6. When the desired value appears, press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (Paper Pick retry).
7. Press
CANCEL
two times.
The LCD returns to the Ready screen.
Paper feed retry
This function sets the feed motor rotation period and the retry count.
Remarks
1 to 7: one time to seven times the standard
steps
1 to 7: one retry to seven retries
LCD display
Paper Feed Retry
Options
Step: 1 to 7 (Default: 1)
Times: 1 to 7 (Default: 4)
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears
2. Press repeatedly until “Paper Feed retry”
appears in the lower line of the menu screen.
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
Paper Feed retry
The following is an example of operation when you use this function.
