Computer Products of America Image Scanner Operator's Guide fi-4990C

6-42
Setup mode lock
This function inhibits the operator panel from entering setup mode from normal mode, protecting the
operator panel from misoperation. Once the operator panel is locked, you cannot use the setup items
except those allocated to the
F1
,
F2
, and
F3
buttons.
NOTE
You cannot use this function when the setup mode is brought by pressing
MENU
in the Ready
status.
RemarksLCD display
Setup Mode Lock
Options
On, Off (Default: Off)
F2 selection
Undefined
F2 selection
EJECT key
Function Key
F1 F2 F3
6. When START key is displayed, press
ENTER
.
The LCD returns to the function key select
screen with F1 blinking.
7. Press once.
F2 blinks.
8. Press
ENTER
.
The F2 selection screen appears with the
current setting Undefined blinking (blinking
indicates “changeable”).
9. Press or .
The setup functions, START key, and EJECT
key are displayed in sequence at the lower line.
10. When EJECT key is displayed, press
ENTER
to save the change.
The LCD returns to the function key select
screen with F2 blinking.
11. To quit the <<SETUP MODE>>, turn off the
power.
Function Key
F1 F2 F3
Function Key
F1 F2 F3
