6-43
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “Setup Mode
Lock” appears in the lower line of the menu
screen.
3. Press
ENTER
.
The option select screen appears with the
current setting OFF blinking (blinking indicates
“changeable”).
4. Press or .
The displayed option changes (ON blinks).
5. Press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (Setup Mode Lock).
6. To quit the <<SETUP MODE>>, turn off the
power.
<<SETUP MODE>>
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
Setup Mode Lock
To cancel the setup mode lock state, turn off the power and turn on the power while pressing the
MENU
button to enter the setup mode. In the setup mode, select the Setup Mode Lock function
and set the option to OFF.
The following is an example of operation when you use this function.
Setup Mode Lock
ON
Setup Mode Lock
OFF
<<SETUP MODE>>
Setup Mode Lock
15C6.P65 01.2.17, 5:47 PM43
