6-44
1. <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “Language”
appears in the lower line of the menu screen.
3. Press
ENTER
.
The current option list screen appears with
English blinking. (blinking indicates “change-
able”).
4. Press or .
The displayed option changes (
blinks).
5. When the desired option appears, press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (Language).
6. Press
CANCEL
two times.
The LCD returns to the Ready screen.
<<SETUP MODE>>
<<SETUP MODE>>
Language
Language
Language
English
<<SETUP MODE>>
language
The following is an example of operation when you change the setting.
Language
This function is to set the LCD display English or Japanese.
RemarksLCD display
Language
Options
English, (Default: English)
<<SETUP MODE>>
Paper Length Check
Ready
