6-46
5. When the desired option appears, press
ENTER
to save the change.
The LCD returns to the <<SETUP MODE>>
menu screen (White follower mode).
6. To quit the <<SETUP MODE>>, turn off the
power.
<<SETUP MODE>>
White follower mode
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press repeatedly until “Interface Board
Slot” appears in the lower line of the menu
screen.
<<SETUP MODE>>
The following is an example of operation when you use this function.
Interface board slot
This function activates one interface board while 2 interface boards are mounting.
NOTE
You cannot use this function when the setup mode is brought by pressing
MENU
in the Ready
status.
RemarksLCD display
Interface Board Slot
Options
AUTO, SLOT1, SLOT2 (Default: AUTO)
<<SETUP MODE>>
Paper Length Check
<<SETUP MODE>>
Interface Board Slot
