P3PC-3272-01EN

Getting Star ted

Thank you for purchasing the color image scanner ScanSnap S1100 (hereinafter

referred to as "the ScanSnap"). This manual describes the preparation required for

use of the ScanSnap. Follow the preparation procedures described in this manual.

For features and functions, basic operations, and daily care of the ScanSnap, refer

to the Operator's Guide which is available on the Setup DVD-ROM. Keep this

manual in a safe place so that you can refer to it at any time when using the

ScanSnap.

Microsoft, Windows, Windows Vista, Excel, and PowerPoint are either registered

trademarks or trademarks of Microsoft Corporation in the United States and/or

other countries.

Apple, the Apple logo, Mac, Mac OS, iPhoto, and Rosetta are trademarks of Apple

Inc.

Other company names and product names are the registered trademarks or

trademarks of the respective companies.

October 2010

Checking the Components

Make sure that all items shown below are included in the package.

If any other packaging is provided, make sure to store it as well. Make sure to

handle the components with care.

The box and packaging materials are required for storage and transportation of the

ScanSnap. Do not throw them away.

If anything is missing or damaged, contact your FUJITSU scanner dealer or an

authorized FUJITSU scanner service provider.

ScanSnap (× 1)

USB cable (× 1)

Setup DVD-ROM (× 1)

Getting Started (× 1)

(This manual)

Rack2-Filer (× 1)

(Exclusive to S1100 with Rack2-Filer)

S1100_GS-SP.book Page 1 Thursday, September 16, 2010 11:45 AM

Summary of content (16 pages)

PAGE 1
S1100_GS-SP.book Page 1 Thursday, September 16, 2010 11:45 AM P3PC-3272-01EN Getting Started Thank you for purchasing the color image scanner ScanSnap S1100 (hereinafter referred to as "the ScanSnap"). This manual describes the preparation required for use of the ScanSnap. Follow the preparation procedures described in this manual. For features and functions, basic operations, and daily care of the ScanSnap, refer to the Operator's Guide which is available on the Setup DVD-ROM.
PAGE 2
S1100_GS-SP.book Page 2 Thursday, September 16, 2010 11:45 AM Read the Safety Precautions Before using the ScanSnap, make sure to read and understand "Safety Precautions" (page 9). Symbols Used in This Manual The following symbols are used in this manual. This symbol alerts operators to particularly important information. Be sure to read this information. This symbol alerts operators to helpful advice regarding operations. This symbol indicates operations using Windows®.
PAGE 3
S1100_GS-SP.book Page 3 Thursday, September 16, 2010 11:45 AM Windows® Installation ■ Software You can install the following software: z z z z ScanSnap Manager (Scanner driver) ScanSnap Organizer (File management application) CardMinder (Business card management application) ABBYY FineReader for ScanSnap (OCR application) To use Evernote for Windows and/or Scan to SharePoint, the required software should also be installed.
PAGE 4
S1100_GS-SP.book Page 4 Thursday, September 16, 2010 11:45 AM ■ Installation 1. 2. Turn on the computer and log on as a user with Administrator privileges. Insert the Setup DVD-ROM into the DVD-ROM drive. D The [ScanSnap Setup] dialog box appears. If the [ScanSnap Setup] dialog box does not appear, double-click "ScanSnap.exe" in the DVD-ROM via Windows Explorer. 3. Click the [Install Products] button. 4. Click the [ScanSnap] button. D The [Install Products] dialog box appears.
PAGE 5
S1100_GS-SP.book Page 5 Thursday, September 16, 2010 11:45 AM ■ System Requirements Operating system (*1) CPU Memory Display resolution Mac OS X v10.6 (*2) Mac OS X v10.5 Mac OS X v10.4 Intel® Core™ 2 Duo 2.4 GHz or higher recommended (Minimum: Intel® Core™ Duo 1.83 GHz, PowerPC® G5 1.6 GHz) 1 GB or more 512 MB or more (1 GB or more recommended) 1024 × 768 pixels or higher Hard disk space 1390 MB or more of free hard disk space USB port (*3) USB 2.0 / USB 1.
PAGE 6
S1100_GS-SP.book Page 6 Thursday, September 16, 2010 11:45 AM Connecting the ScanSnap zOnly one ScanSnap can be connected to a computer at a time. zUse only the cable supplied with the ScanSnap. 1. 2. Remove the tape on the ScanSnap. and seal Connect the USB cable to the USB connector on the ScanSnap and the USB port on your computer. zWhen connecting to USB hub, make sure to connect the ScanSnap to the USB hub which is connected to a USB port of your computer. Use a powered USB hub (with AC adaptor).
PAGE 7
S1100_GS-SP.book Page 7 Thursday, September 16, 2010 11:45 AM In Windows® 7, the ScanSnap Manager icon is displayed in the menu which appears when you click on the taskbar. To have the ScanSnap Manager icon always displayed on the taskbar, drag the icon and drop it onto the taskbar. Scan Test For details on documents that can be scanned with the ScanSnap and how to load documents, refer to "ScanSnap Overview" in the Operator's Guide. 1.
PAGE 8
S1100_GS-SP.book Page 8 Thursday, September 16, 2010 11:45 AM Contact for Inquiries Refer to the contact list on the last page of this document.
PAGE 9
S1100_GS-SP.book Page 9 Thursday, September 16, 2010 11:45 AM Safety Precautions This section contains the general information for safety that must be read before using the ScanSnap. Read this document and Operator's Guide thoroughly and take care to use the ScanSnap correctly. Use in High-Safety Applications This product has been designed and manufactured on the assumption that it will be used in office, personal, domestic, regular industrial, and general-purpose applications.
PAGE 10
S1100_GS-SP.book Page 10 Thursday, September 16, 2010 11:45 AM Warning Indications Used in This Document The following indications are used in this document to obviate any chance of accident or damage to you and/or the ScanSnap. Warning Indication Description WARNING This indication alerts operators to an operation that, if not strictly observed, may result in severe injury or death.
PAGE 11
S1100_GS-SP.book Page 11 Thursday, September 16, 2010 11:45 AM Firmly insert the USB cable into the ScanSnap and computer. Not doing so may cause a fire or the ScanSnap to malfunction. Use only the USB cable provided with the ScanSnap. Not doing so may cause abnormal heat or a fire. Do not use the USB cable provided with the ScanSnap for other devices, since this may cause problems such as an equipment failure, or an electric shock.
PAGE 12
S1100_GS-SP.book Page 12 Thursday, September 16, 2010 11:45 AM Do not swing around, drop, or throw the ScanSnap. It may hit an object or person, resulting in a damage or injuries. Do not place heavy objects on the ScanSnap or perform other work on top of the ScanSnap. Make sure not to sit down with the ScanSnap in your pocket, or put heavy objects on top of the ScanSnap if carrying it in a bag.
PAGE 13
S1100_GS-SP.book Page 13 Thursday, September 16, 2010 11:45 AM Install the ScanSnap away from strong magnetic fields and other sources of electronic noise. Protect the ScanSnap against any static electricity and choose a static-free place to install the ScanSnap. Static electricity can cause the ScanSnap to malfunction. If there is an electrical storm, disconnect the USB cable from the ScanSnap and computer. Not doing so may destroy the ScanSnap, which may damage your properties.
PAGE 14
S1100_GS-SP.book Page 14 Thursday, September 16, 2010 11:45 AM Disclaimer of Liability ■Reproducibility of the Scanned Image Data Confirm that the image data scanned with this product meets your requirements (for example, image reproducibility in size accuracy, fidelity, content, colors). Make sure that there are no missing parts in the scanned image data before disposing of the original document used for scanning.
PAGE 15
S1100_GS-SP.book Page 15 Thursday, September 16, 2010 11:45 AM Regulatory Information FCC Declaration This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
PAGE 16
S1100_GS-SP.book Page 16 Thursday, September 16, 2010 11:45 AM Safety Standards for LED Products Class 1 LED Product This product is classified as a Class 1 LED product, which conforms to IEC 60825-1, an international standard for laser products, and EN 60825-1, a standard adopted by CENELEC (Comité Européen de Normalisation Électrotechnique).
