Technical data

Data Sheet Fujitsu PRIMERGY MX130 S2 Server
Page 3 / 6 www.fujitsu.com/fts
Technical details
Mainboard
Mainboard type D3090
Chipset AMD 880G
Processor quantity and type 1 x AMD Sempron™ / AMD Athlon™ II / AMD Phenom™ II (only available in Continental Europe, Middle East, Africa
and India) / AMD Opteron™ 3200 Series (available on project request in Continental Europe, Middle East, Africa and
India)
Processor AMD Athlon™ II X2 220
(2 Cores, 2.8 GHz, SLC: 1 MB)
AMD Athlon™ II X2 265
(2 Cores, 3.3 GHz, SLC: 2 MB)
AMD FX 4100
(4 Cores, 3.6 GHz, SLC: 8 MB)
AMD Phenom™ II X6 1065T
(6 Cores, 2.9 GHz, SLC: 9 MB)
AMD Sempron™ 145
(1 Core, 2.8 GHz, SLC: 1 MB)
Memory slots 4
Memory slot type DIMM (DDR3) ECC
Memory capacity (min. - max.) 2 GB - 16 GB
Memory protection ECC
Memory notes Mix and match possible, with dual channel operation better performance (2 modules with equal capacity necessary).
Single channel (1 module) conguration possible.
Memory options 2 GB (1 module(s) 2 GB) DDR3, ECC, 1333 MHz, PC3-10600, DIMM
4 GB (1 module(s) 4 GB) DDR3, ECC, 1333 MHz, PC3-10600, DIMM
Interfaces
USB ports 12 (2 x front, 6 x back, 4 x internal)
DVI 1 (Dual link DVI-I), ATI Radeon® HD 4250 (up to 2811MB) on board
Graphics (15-pin) 1 No dedicated 15-pin VGA port available. VGA is available via the supplied DVI to VGA adapter.
Audio: line-in 1
Audio: line-out 1
Audio: microphone 1
Audio: comments For projects only
Serial connection 1 9pin, 16 byte FIFO, 16550 compatible
Mouse / Keyboard (PS/2) 2
LAN / Ethernet (RJ-45) 1 Gbit/s Ethernet
Status LEDs Power (green)
I/O controller on board
RAID controller 6 port SATA with RAID 0/1/10 for HDDs
SATA Controller SATA II
LAN Controller BCM 57780, 10/100/1000 Mbit/s Ethernet, PXE-Boot by LAN via PXE-Server
Trusted Platform Module (TPM) Inneon / 1.2 (option)
Slots
PCI-Express 2.0 x4 1 x Low prole max. length 180mm
PCI-Express 2.0 x16 1 x Low prole max. length 180mm
PCI-Express x1 1 x Low prole max length 85mm
PCI-slots 1 x Low prole max. length 180mm
Slot Notes PCI 32/33 MHz, 3.3V/5V
Storage drive bays 4 x 3.5-inch non hot-plug SATA
