Technical data

Data Sheet Fujitsu PRIMERGY MX130 S2 Server
Page 4 / 6 www.fujitsu.com/fts
Storage drive bay conguration Maximum 4x 3.5” HDDs possible.
2x HDD with easy change, 2x with screw-in.
Alternatively 2.5” HDDs possible, max. 6x 2.5” possible.
2.5-inch HDDs available on project request.
Accessible drive bays 1 x 5.25/1.6-inch for backup devices or CD-RW/DVD
Notes accessible drives 1x slimline DVD accessible.
Alternatively to slimline DVD a 4th 3.5” HDD can be used.
Number of fans 3
Fan conguration Front-fan, CPU-fan, PSU-fan
Fan notes Non hot plug
Operating panel
Operating buttons On/off switch
Status LEDs Power (green)
Operating systems
Certied or supported operating
systems and virtualization software
Microsoft® Hyper-V™ Server 2008 R2
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Foundation
Microsoft® Windows® Small Business Server Essentials 2011
Operating system release link http://docs.ts.fujitsu.com/dl.aspx?id=a9e600b9-e4cb-4f48-aa41-632f69058421
Operating system notes Novell® certication
Red Hat® certication
Support of other Linux derivatives on demand
Server Management
Dimensions / Weight
Floor-stand (W x D x H) 98 x 383 x 340 mm
Dimension notes Dimensions in vertical position (excluding feet)
Weight approx. 8 kg
Weight notes Actual weight may vary depending on conguration
Environmental
Operating ambient temperature 10 - 35°C
Operating environment FTS 04230 – Guideline for Data Center (installation locations)
Operating environment Link http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Noise emission According to ISO9296
Sound pressure (LpAm) 20 dB(A) (idle)/ 20 dB(A) (operating); may vary according to conguration.
Sound power (LWAd; 1B = 10dB) 3.5B (idle) / 3.5B (operating); may vary according to conguration.
Electrical values
Power supply conguration 1
Max. output of single power supply 250 W
Power supply efciency 85%
Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Rated current max. 3.5 A - 1.5 A (100 V / 240 V)
Active power (max. conguration) 159 W
Heat emission 572.4 kJ/h (542.5 BTU/h)
Compliance
Product PRIMERGY MX130 S2
Model DT8-D3090
Germany GS
Europe CE Class A *
USA/Canada FCC Class A
CSAc/us
