2-8 C120-E360-06EN
CHAPTER 2 Setup of the RCI for Operation
2.4.5 Making an RCI expansion setting
The added RCI host must be connected to the RCI network.
The RCI address of the added RCI host is synchronized with those of existing RCI
hosts so that the added cabinet can use RCI functions.
Make an RCI expansion setting on the added RCI host.
Note: Before beginning this RCI setup work, confirm that AC cables are connected
to all RCI units.
Note: To make an RCI expansion setting for an RCI unit equipped with a main line
switch, set the main line switch to the ON position.
• To make an RCI expansion setting:
1 Execute the setrci (8) command, and make an RCI expansion setting.
• To confirm an RCI expansion setting:
1 Execute the setrci (8) command to display the RCI status.
Confirm that the displayed LIST contents include the added RCI host.
For details on LIST contents, see Chapter 3, "Command Reference."
XSCF> setrci -c addconfig
....................................................
The command completed successfully.
XSCF> setrci -c stat
HOST
address 000102ff
Active
LIST
address pwr alm I/F sys-phase tgry dev-cls sub-cls tm-out
000101ff OFF - ACT - host 0001 0b -
000102ff OFF - ACT - host 0001 0b -
003001ff OFF - ACT - disk 0400 04 -
The command completed successfully.
