2-14 C120-E360-06EN
CHAPTER 2 Setup of the RCI for Operation
• To confirm the specified RCI address:
1 Execute the setrci (8) command to display the RCI status.
Confirm that the "address" value is correct.
To correct the RCI address, start again from RCI initialization.
2.6.6 Making an RCI replacement setting
The new RCI host must be connected to the RCI network.
The RCI address of the new RCI host is synchronized with those of existing RCI hosts
so that the new cabinet can use RCI functions.
An RCI replacement setting can be made on the new RCI host.
Note: Before beginning this RCI setup work, confirm that AC cables are connected
to all RCI units.
Note: To make an RCI replacement setting for an RCI unit equipped with a main
line switch, set the main line switch to the ON position.
• To make an RCI replacement setting:
1 Execute the setrci (8) command, and make an RCI replacement setting.
XSCF> setrci -c stat
HOST
address 000102ff
Inactive
The command completed successfully.
XSCF> setrci -c replaceconfig
....................................................
The command completed successfully.
