C120-E360-06EN 3-1
CHAPTER 3 Command Reference
1
3.1 setrci
•NAME
setrci - configure or display the environment of the remote cabinet interface (RCI)
•SYNOPSIS
setrci -c stat
setrci -c init [-s RCI_network]
setrci -c set host_no
setrci -c initconfig [-s RCI_network]
setrci -c addconfig [-s RCI_network]
setrci -c replaceconfig [ RCI_address]
setrci -c ledon RCI_address
setrci -c ledoff
setrci -c idpin
setrci -h
• DESCRIPTION
The setrci(8) command configures or displays information that accompanies the
initial setting and maintenance of the RCI environment.
The following can be set or displayed:
stat Displays the status of the RCI network.
init Initializes the RCI setting. Initialization is only performed for the host
that executes the command. If there are other hosts connecting to the
RCI, initialization must be performed for each host.
set Sets an RCI address. Use this specification when the RCI setting has been
initialized. After the setting, "-c initconfig" or "-c addconfig" must be
executed.
initconfig Makes the RCI setting on the first host. An RCI I/O unit connected via
RCI is searched for and found, and then an RCI address is assigned.
