C120-E360-06EN 3-9
3.2 setrcic
•OPTIONS
The following options are supported:
•OPERANDS
The following operands are supported:
• EXTENDED DESCRIPTION
z When the setrci(8) command or setrcic(8) command is being executed on another
host in the RCI network, do not execute the setrcic(8) command.
z When the setrcic(8) command is executed, set all RCI units that are connected to
RCI into the power-on state or standby state.
z Executing the setrcic(8) command on a model that does not support the RCI
function causes an error to occur.
-c exrdy
RCI_address
[time]
Sets the EXRDY monitoring timeout period of the specified external
power control devices. Set the EXRDY monitoring timeout period in
units of minutes for time. If 0 is specified, EXRDY monitoring is
disabled. If time is omitted, the EXRDY monitoring timeout period is
displayed.
-c opcalldisp Displays the status of the operator call signals of the specified external
power control devices.
-c opcallon
RCI_address
callNo
Sets the operator call signals of the specified external power control
devices on. Setting is made for the devices corresponding to the bits of
callNo that contain "1".
-c opcalloff
RCI_address
callNo
Sets the operator call signals of the specified external power control
devices off. Setting is made for the devices corresponding to the bits of
callNo that contain "1".
-h Displays usage statement. When used with other options or operands, an
error occurs.
RCI_address Specifies a target RCI address. A value in any of the following ranges
can be specified for RCI_address:
003001ff-00307fff
007001ff-00707fff
time Sets the EXRDY monitoring timeout period when "-c exrdy" is specified
in units of minutes. Any decimal integer number ranging from 0 to 85
can be specified.
callNo Specifies operator call information. A two-digit hexadecimal number
can be specified.
