Data Sheet

DATASHEET FUJITSU LIFEBOOK NH570 NOTEBOOK
Page 3 / 6 http://ts.fujitsu.com/mobile
Windows
®
. Life without Walls™.
Fujitsu recommends Windows 7.
GRAPHICS
TFT resolution (VGA) up to 1920 x 1200 up to 1920 x 1200
Max. resolution external display up to 1920 x 1200 up to 1920 x 1200
Graphics brand name Intel
®
HD Graphics NVIDIA
®
GeForce
®
GT 330M
Graphics features DirectX
®
10 support DirectX
®
10 support
Graphics notes With 64-bit Windows
®
7 operating systems, shared video
memory sizes are as follows:
- 2048 MB system memory enables up to 729 MB static and
shared memory
- 4096 MB system memory enables up to 1695 MB static
and shared memory
- 8192 MB system memory enables up to 1695 MB static
and shared memory
Dedicated video memory 1 GB
Shared video memory up to 1695 MB
INTERFACES
Memory card slots 1 (supported formats: SD, SDHC, MS, MMC) 1 (supported formats: SD, SDHC, MS, MMC)
ExpressCard slots 1 (34/54 mm) 1 (34/54 mm)
eSATA 1 1
USB 2.0 total 3 3
FireWire (IEEE1394) 1 1
VGA 1 1
HDMI 1 1
Ethernet (RJ-45) 1 1
DC-in 1 1
Audio: headphone out 1
Audio: microphone 1 1
Audio: headphone out / SPDIF 1
Audio: line-in 1 1
Internal microphones 1 (digital) 1 (digital)
Kensington Lock support 1 1
WIRED COMMUNICATION
LAN 10/100/1000 MBit/s
KEYBOARD AND POINTING DEVICES
Spill-resistant keyboard with number block
Number of keyboard keys: 106, Keyboard pitch: 19.05 mm, Keyboard stroke: 2.5 mm
Multi gesture touchpad with two mouse buttons and one
scroll button
Status LED
Multi gesture touchpad with two mouse buttons and
ngerprint sensor
Status LED
MULTIMEDIA
Audio type On board
Audio features Support of high-denition audio, 2x built-in speakers (stereo), Built-in digital microphone, Sound volume control via function
key
Camera Built-in webcam, 1.3 megapixel
POWER SUPPLY
AC adapter 19 V / 80 W (4.22 A) 19 V / 100 W (5.27 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
1st battery Li-Ion battery 6-cell, 5200 mAh, 56 Wh Li-Ion battery 8-cell, 5200 mAh, 75 Wh
Benchmark Mobile Mark 2007 (readers mode – e.g. surng the internet, writing E-mails, viewing documents)
Runtime 1st battery Up to 3:30 h
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features
utilized. Battery recharge time varies depending on usage. The recharge capacity may decrease after some months so that
the battery lifetime as well as operating time can not be assured for the whole lifetime of the notebook.
