Data Sheet

DATASHEET FUJITSU LIFEBOOK P8110 NOTEBOOK
Page 2 / 6 http://ts.fujitsu.com/mobile
COMPONENTS
MEMORY MODULES 2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
3 GB (2 module(s) 1 GB and 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
4 GB (2 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
Supported capacity RAM (max.) 4 GB
Memory slots total 2
Memory slot type DIMM
Memory notes 8 GB - with future memory modules.
HARD DISK DRIVES (INTERNAL) 320 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.
320 GB, 5400 rpm, FDE, 2.5-inch S.M.A.R.T.
160 GB, 7200 rpm, SATA, 2.5-inch S.M.A.R.T.
160 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.
128 GB SSD SATA, 2.5-inch S.M.A.R.T.
Hard disk notes ShockSensor for HDD shock protection
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Accessible capacity may vary, also depending on used software
WLAN (OPTIONAL) Atheros Minicard b/g/n
Intel
®
Wireless WiFi Link 5300 AGN 11/13ch
WIRELESS TECHNOLOGIES
Antennas 3 Dual band WLAN antennas, 2 UMTS antennas
WLAN notes Import and usage according to country-specic regulations.
3G/UMTS (OPTIONAL) Sierra Wireless Gobi 2000 (downlink 7.2 Mbit/s, uplink 5.76 Mbit/s)
BLUETOOTH (OPTIONAL) Bluetooth 2.1
Base unit LIFEBOOK P8110
GENERAL SYSTEM INFORMATION
Processor Intel
®
Core™2 Duo processor SU9600 (1.6 GHz), 3 MB, 800 MHz
Chipset Intel
®
GS45, ICH9-M
BIOS features BIOS Flash EPROM
BIOS based on Phoenix TrustedCore Notebook
PRODUCT DESIGN
Material Glossy black
Matt black
GRAPHICS
Max. resolution external display 1920 x 1200 / true color / 60 Hz
Graphics brand name Mobile Intel
®
GMA 4500M HD
Graphics features DualView (Windows
®
XP & Windows
®
Vista)
INTERFACES
Memory card slots 1 (SD)
ExpressCard slots 1
SIM card slot 1
USB 2.0 total 3
VGA 1
HDMI 1
Ethernet (RJ-45) 1
DC-in 1
Audio: line-in / microphone 1
Audio: line-out / headphone 1
