System Operating manual LIFEBOOK T732
Congratulations on your purchase of an innovative product from Fujitsu. The latest information about our products, tips, updates etc. can be found on the Internet at: "http://www.fujitsu.com/fts/" For automatic driver updates, go to: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact: • our Hotline/Service Desk (see the Service Desk list or visit: "http://support.ts.fujitsu.
Published by Fujitsu Technology Solutions Mies-van-der-Rohe-Straße 8 (Mies-van-der-Rohe Street No. 8) 80807 Munich, Germany Contact http://www.fujitsu.com/fts/ Copyright © Fujitsu Technology Solutions 2012. All rights reserved. Publication Date 10/12 Order No.
LIFEBOOK T732 Operating manual Innovative technology 7 Ports and controls 9 Important notes 12 First-time setup of your device 15 Working with the notebook 18 Security functions 68 Connecting external devices 75 Removing and installing components during servicing 82 Settings in BIOS Setup Utility 90 Troubleshooting and tips 92 Technical data 99 Manufacturer’s notes 102 Index 108
Remarks Information on the product description meets the design specifications of Fujitsu and is provided for comparison purposes. Several factors may cause the actual results to differ. Technical data is subject to change without prior notification. Fujitsu rejects any responsibility with regard to technical or editorial mistakes or omissions. Trademarks Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited or its subsidiaries in the United States and other countries.
Contents Contents Innovative technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Notational conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Removing a module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Installing a module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optical drive . . . . . . . . . .
Contents HDMI port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Connecting USB devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USB port with charging function (Anytime USB charge) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . How to remove USB devices correctly . . . . . . . . . . . . . . . . . . .
Contents Notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 Port Replicator (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Rechargeable battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Innovative technology Innovative technology ... and ergonomic design make your device a reliable and convenient companion. The device boots very quickly, is ready for immediate use and offers a particularly long operating time because of its high capacity battery. With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better protect your system against unauthorised access by using the powerful password properties.
Innovative technology Notational conventions Pay particular attention to text marked with this symbol. Failure to observe these warnings could pose a risk to health, damage the device or lead to loss of data. The warranty will be invalidated if the device becomes defective through failure to observe these warnings. Indicates important information for the proper use of the device.
Ports and controls Ports and controls This chapter presents the individual hardware components of your device. It gives you an overview of the device’s indicators and connections. Please familiarise yourself with these components before you start to work with the device.
Ports and controls Left panel 1 2 1 = DC input connector (DC IN) 2 = HDMI port 3 3 = USB port with charging function (Anytime USB charge, USB 3.0) Rear 1 1 = Security Lock device 2 = VGA monitor port 10 2 3 4 3 = USB ports (USB 2.
Ports and controls Right-hand side 1 3 2 4 3 = Module bay with optical drive 4 = Eject lever for module bay 1 = Pen slot 2 = ExpressCard slot Bottom 1 2 3 7 6 1 2 3 4 = = = = Hard disk service compartment Memory service compartment Attachment eye for the pen cord Battery with SIM card slot under the battery Fujitsu 5 4 5 = Battery charge status indicator 6 = Port for port replicator 7 = Ventilation slot cover 11
Important notes Important notes Notes Importantnotes This chapter contains essential safety information which must be followed when working with your notebook. Other notes also provide useful information which will help you with your notebook. Safety notes Notes Safetynotes Please follow the safety notes provided in the "Safety/Regulations" manual as well as the safety notes given below. Please pay special attention to the sections in the manual marked with the symbol on the left.
Important notes Energy saving Energysaving Energy Notes Switch the notebook off when it is not in use. Switch off external, connected devices if you are not using them. If you use the energy saving functions, the notebook uses less energy. You will then be able to work for longer before having to recharge the battery. Energy efficiency is increased and the environmental impact is reduced. You save money while protecting the environment.
Important notes Notebook: transporting Protect the notebook from severe shocks and extreme temperatures (e.g. direct sunlight in a car). ► ► ► ► ► ► If your device has an optical drive, remove all data media (e.g. CD, DVD) from the drives. Switch the notebook off. Unplug the mains adapter and all external devices from the power socket. Disconnect the mains adapter cable and the data cables for all external devices. Close the LCD screen.
First-time setup of your device First-time setup of your device Gettingstarted First-timesetup Please read the chapter "Important notes", Page 12. If your device is equipped with a Windows operating system, the necessary hardware drivers and supplied software are already pre-installed. Before you switch on the device for the first time, connect it to the mains voltage using the mains adapter, see "Mains adapter connecting", Page 16.
First-time setup of your device Selecting a location Selectinga location Mainsadapter Device Select a suitable location for the device before setting it up. Follow the instructions below when doing so: • Never place the device or the mains adapter on a heat-sensitive surface. The surface could be damaged as a result. Never place the device on a soft surface (e.g. carpeting, upholstered furniture, bed). This can block the air vents and cause overheating and damage.
First-time setup of your device Switching on the device for the first time Switchingon for thefirsttime On devices with ON/OFF switch for wireless components: Slide the ON/OFF switch for wireless components to the ON position before switching on the device. When you switch on the device for the first time, the supplied software is installed and configured.
Working with the notebook Working with the notebook Notebook Notebook,operation This chapter describes the basics for operating your notebook. Please read the chapter entitled "Connecting external devices", Page 75 for instructions on how to connect devices such as a mouse and a printer to the notebook. Please refer to the notes in "Important notes", Page 12.
Working with the notebook Status displays Description Power-on indicator • Indicator is illuminated: The notebook is switched on. • Indicator flashes: The notebook is in sleep mode (Save-to-RAM). • The indicator is not illuminated: The notebook is switched off or in Save-to-Disk mode. Battery charging indicator The battery charging indicator shows whether a battery is installed and being charged. Battery indicator This description applies for both batteries.
Working with the notebook Opening the notebook 1 ► Open the LCD screen.
Working with the notebook Switching on the notebook Notebook:switching on Suspend/Resumebutton Power-onindicator 1 ► Slide the ON/OFF switch (1) to the right to switch on the notebook. The ON/OFF switch returns automatically to its original position. The ON/OFF switch (1) lights up whenever the system is switched on.
Working with the notebook Different ways to use your notebook During your daily work, you can use your notebook as a tablet PC or as a notebook, just as you wish. Note the direction of rotation in the following description! No guarantee claims can be met for damage caused by turning in the wrong direction. You must note that the display cannot be turned completely on its own axis! From notebook to Tablet PC ► Raise the LCD display into a vertical position.
Working with the notebook ► Hold the screen as low as possible on both sides. Turn the screen to the left or right in the direction of the arrow. At first you will feel some slight resistance, then it will turn easily and without friction. ► Turn the display further until it has turned 180° and the hinge latches in.
Working with the notebook ► Now fold the screen down until the back of the screen is flat on top of the keyboard. The screen is now secured in the tablet position. Select display orientation (portrait or landscape orientation) Displayorientation Portraitorientation Landscapeorientation You can choose to use either portrait or landscape orientation for the display.
Working with the notebook From Tablet PC to notebook 1 ► Raise the LCD screen into a vertical position.
Working with the notebook Note the direction of rotation in the following description! No guarantee claims can be met for damage caused by turning in the wrong direction. ► hold the screen as near to the bottom as possible on both sides and turn the screen in the direction indicated by the rotational direction indicator. It will turn easily and without resistance. ► Turn or move the display further until it has turned 180° and the hinge latches in.
Working with the notebook Closing the notebook ► Fold the LCD screen down onto the lower part of the notebook until you feel it lock into place.
Working with the notebook LCD screen Notes LCDscreen High-quality TFT displays are installed in notebooks from Fujitsu Technology Solutions GmbH. For technical reasons, TFT monitors are manufactured for a specific resolution. An optimal, clear picture can only be ensured with the correct resolution intended for the relevant TFT monitor. A monitor resolution which differs from the specification can result in an unclear picture.
Working with the notebook Using fingers You can execute certain commands by using your finger tip on the touchscreen of your device. Everything which you can select or activate using your finger tip can also be selected or activated using the stylus pen. Calibrate the Dual Digitizer for finger-based operation of the device. Please see the appropriate supplementary sheet for instructions on how to calibrate your device to use Dual Digitizer Technology.
Working with the notebook Actions with two fingers Action Scrolling Description ► Position two fingers on the touchscreen. ► Move your fingers upwards to scroll up. or ► Move your fingers downwards to scroll down. Rotating ► Position the thumb on the touchscreen, then turn the picture clockwise or counter-clockwise using your index finger.
Working with the notebook Action Increasing or decreasing the view Description ► Position two fingers on the touchscreen and move them apart to increase the view. or Blocking context-sensitive menus Fujitsu ► Position two fingers on the touchscreen and move them together to decrease the view. ► With two fingers, tap twice briefly in quick succession on the touchscreen.
Working with the notebook Using the stylus pen 1 = pen tip 3 4 2 = rocker button 3 = eyelet for pen cord 4 = eraser 2 1 You can use the pen on your notebook as an electronic writing implement to select items and to navigate through menu options and programs. Programs that support handwriting recognition also allow you to write characters directly on the screen with the pen. You can also use the pen as a drawing tool. The notebook pen is retained securely in the pen slot.
Working with the notebook The pen of your notebook is an electronic instrument which can be damaged if used incorrectly. Handle the pen with care. The following list contains guidelines for proper pen handling: • • • • Do not gesture with the pen. Do not use the pen as a pointer. Never use the pen on any other surface than the screen of your notebook. Do not try to turn the thumb grip on the pen. The thumb grip is used to place the pen in its slot and to take it out of the slot.
Working with the notebook Calibrating the pen Before using the pen for the first time, you should calibrate it so that the cursor follows the movements of the pen as accurately as possible. You should also always repeat the calibration if the co-ordination between the pen and cursor movement deteriorates. Operating system Windows 7 Menu To calibrate, call up the Hardware and Sound / Tablet PC Settings function in the Control Panel. You need to calibrate both portrait and landscape formats.
Working with the notebook Using the device as a notebook Touchpad and touchpad buttons Keep the touchpad clean. Protect it from dirt, liquids and grease. Touchpad Do not use the touchpad if your fingers are dirty. Do not rest heavy objects (e.g. books) on the touchpad or the touchpad buttons. 1 = Touchpad 1 2 = Touchpad buttons 2 The touchpad enables you to move the mouse pointer on the screen. The touchpad buttons allow you to select and execute commands.
Working with the notebook Dragging items ► Select the desired item. ► Press and hold the left button and drag the item to the desired position with the finger on the touchpad. The item will be moved. Touchpad Switching the Touchpad on and off You can switch the Touchpad on and off using a key combination, see "Key combinations", Page 40.
Working with the notebook Keyboard Keyboardkeypad Numeric Buttons The keyboard of your notebook is subject to continuous wear through normal use. The key markings are especially prone to wear. The key markings are liable to wear away over the life of the notebook. The keyboard has been designed to provide all the functions of an enhanced keyboard. Some enhanced keyboard functions are mapped with key combinations. The following description of keys refers to Windows.
Working with the notebook Key Description Backspace key The Backspace key deletes the character to the left of the cursor. Backspace Tab key The Tab key moves the cursor to the next tab stop. Tabkey Enter key (return) The Enter key terminates a command line. The command you have entered is executed when you press this key. Linefeed Enter Return Enterkey Caps Lock key The Caps Lock key activates the Caps Lock mode, and the corresponding icon is displayed in the Windows information area.
Working with the notebook Virtual numeric keypad Numeric Num Virtualnumerickeypad Lock keypad To provide the convenience of a numeric keypad, your keyboard is equipped with a virtual numeric keypad. The special keys of the virtual numeric keypad are recognisable by the numbers and symbols printed in the upper right corner of each key. If you have switched on the virtual numeric keypad, you can output the characters shown on the upper right of the keys.
Working with the notebook Key combinations The key combinations described below apply when using Microsoft Windows operating systems. Some of the following key combinations may not function in other operating systems or with certain device drivers. Key combinations are entered as follows: ► Press the first key in the combination and keep it pressed. ► While holding the first key down, press the other key or keys in the combination.
Working with the notebook Combination Description Toggle output screen Use this key combination to select which screen(s) is/are used for display if an external monitor is connected. Toggleoutputscreen Fn+F10 Screen output is possible: • • • only on the notebook’s LCD screen only on the external monitor on the notebook’s LCD screen and the external monitor at the same time. Press the key combination several times to switch through all possible settings.
Working with the notebook Tablet buttons Your notebook has six multifunctional tablet buttons. You can navigate on the screen with a simple press of a button, call preset applications or ones that you have set yourself. The tablet buttons have different uses in different modes. In addition, you can still individually program some of the tablet buttons, see "Programming the tablet buttons", Page 43.
Working with the notebook Basic functions when the device has booted Button Basic function Windows button This button corresponds to the function of the Windows Start key on a keyboard. If the button is pressed in combination with the ON/OFF switch, the function corresponds to the key combination Ctrl + Alt + Del . Decrease volume This button reduces the volume of the built-in loudspeakers. Increase volume This button increases the volume of the built-in loudspeakers.
Working with the notebook Webcam Webcam Depending on the software used, you can use your Webcam to take pictures, record video clips or take part in web chats. • • • • The picture quality depends on the lighting conditions and the software being used. You can only operate the webcam with a particular application (e.g. an Internet telephony program or a video conferencing program which supports a webcam). When using the webcam the notebook support must not wobble.
Working with the notebook Rechargeable battery Life,battery Battery Rechargeablebattery When not plugged into a mains socket, the notebook runs on its built-in battery. You can increase the life of the battery by caring for the battery properly. The average battery life is around 500 charge/discharge cycles. You can extend the battery life by taking advantage of the available energy saving functions.
Working with the notebook Removing and installing the battery Only use rechargeable batteries approved by Fujitsu Technology Solutions for your notebook. Never use force when fitting or removing a battery. Make sure that no foreign bodies get into the battery connections. Never store a battery for longer periods in the discharged state. This can make it impossible to recharge. Removing the battery ► Prepare for removal, see chapter "Preparing to remove components", Page 83.
Working with the notebook Inserting battery 3 2 1 ► ► ► ► Place the battery on the lower edge of the battery compartment (1). Slide the battery into the battery compartment until you feel it engage (2). Slide the release button into its locked position (3). Complete the removal, see chapter "Finishing component removal", Page 89.
Working with the notebook Battery charge status indicator You can check the charge status directly on the battery itself. a 1 ► Press the key (1). The LED (a) lights up in one of the following colours: LED indicator Green Orange Red LED not lit 48 State of charge The battery is between 50 % and 100 % charged. The battery is between 11 % and 49 % charged. The battery is between 1 % and 10 % charged. The battery is fully discharged.
Working with the notebook Module Modules Modulebay The design of your notebook enables the flexible use of notebook batteries and drives. The following modules can be operated in the module bay of your notebook: • • • Second battery Optical drive Empty plug-in unit (save weight) Only use modules designed for your notebook. Do not use force when installing or removing the module. Make sure that no foreign objects enter the module bay. You can swap modules during operation.
Working with the notebook Installing a module ► Place the module into the module bay so that the contacts enter first. ► Push the module into the module bay until you feel it locking into place. Optical drive Opticaldrive This product contains a light emitting diode, classification according to IEC 60825 1:2007: LASER CLASS 1, and must therefore not be opened.
Working with the notebook CD/DVD indicator CD/DVDindicator The CD/DVD indicator flashes when a data carrier is inserted. The indicator goes out when the drive is ready for reading. The indicator lights up when the drive is being accessed. You may only remove the data carrier when the indicator is unlit. If the CD/DVD indicator does not go out after a data carrier has been inserted, but instead continues to flash, this means that the drive cannot access the data carrier.
Working with the notebook Manual removal (emergency removal) Emergencyremovalofdata carrier Manualremovalofdatacarrier CD/DVD: In the event of a power failure or damage to the drive, you can remove the data carrier manually. ► Switch your notebook off. ► Push a pen or a piece of wire (such as a paperclip) firmly into the opening (1). The drive tray is ejected. You can now pull the drive tray (2) out of the drive.
Working with the notebook ► Insert the ventilation slot cover into the slot (1) at an angle as shown, and ensure that you feel it click into place. ► Complete the removal, see chapter "Finishing component removal", Page 89.
Working with the notebook Using the power-management features Power Battery The notebook uses less power when the available power-management features are used. You will then be able to work longer when using the battery before having to recharge it. Power efficiency is increased and environmental pollution reduced. By choosing the best power options, you can make significant savings and at the same time help protect the environment.
Working with the notebook Memory cards Slot Your notebook is equipped with an integrated memory card reader. Observe the manufacturer’s instructions when handling the memory cards. Memory card Supported format The memory card reader supports the following format: • Secure Digital (SDTM card) Inserting the memory card ► Carefully slide the memory card into the slot. The label should be facing upward. Do not apply excessive force, as otherwise the delicate contact surfaces could be damaged.
Working with the notebook Removing the memory card Memorycard In order to protect your data, always follow the correct procedure for removing the card outlined below. You can stop the memory card via the corresponding icon in the task bar: ► Left-click on the icon. ► Select the card you want to stop and remove. ► Press the Enter key. Wait for the dialogue box which tells you that it is now safe to remove the memory card. ► On devices with card locking: Press on the storage card (1).
Working with the notebook Inserting the card Keep the placeholder for the slot in a safe place. When you remove the card again, you must reinstall the place holder. This prevents foreign objects from getting into the slot. ► Press the edge of the placeholder (1) to make the card placeholder protrude from the notebook’s case. ► Pull the card placeholder out of the slot (2). 1 2 ► Insert the card into the slot guide with the connection contacts first.
Working with the notebook Removing the card Always remove the card according to the rules described below, to ensure that none of your data is lost. You can stop the ExpressCard using the corresponding symbol in the task bar: ► Click on the symbol for safe removal of hardware with the left mouse button. ► Select the ExpressCard you want to stop and remove. ► Press the Enter key. Wait for the dialogue box which tells you that it is now safe to remove the ExpressCard.
Working with the notebook SIM card A SIM card (Subscriber Identity Module) is a chip card which is inserted in a mobile phone or notebook and, together with an integrated UMTS/LTE module, enables access to a mobile network. When handling SIM cards, follow the instructions supplied by the provider. Inserting the SIM card ► Prepare for installation of the SIM card, see chapter "Preparing to remove components", Page 83.
Working with the notebook Optional Wireless LAN / Bluetooth / UMTS / LTE wireless components The installation of radio components not approved by Fujitsu Technology Solutions will invalidate the certifications issued for this device. Depending on the device configuration you ordered, your device will be equipped with Wireless LAN, Bluetooth and/or UMTS / LTE.
Working with the notebook Setting up WLAN access • Requirement: A WLAN must be available and you must have the corresponding access information. Information on configuring the WLAN access can be found in the documentation for your operating system. Access via UMTS / LTE If you ordered an integrated UMTS / LTE module with your system, you can enjoy optimum reception and maximum energy efficiency without awkward cables or antennas. The optional UMTS / LTE module is ready for use straight away.
Working with the notebook Ethernet and LAN EthernetLAN The internal network module of your notebook supports Ethernet LAN. You can use it to establish a connection to a local network (LAN = Local Area Network). ► Connect the network cable to the LAN port of the notebook (1). ► Connect the network cable to your network connection (2). 1 2 Your network administrator can help you to configure and use the LAN connections. The network cable is not included in the delivery scope.
Working with the notebook Ports on the Port Replicator Ports PortReplicator 1 10 2 3 4 5 6 7 8 9 12 11 1 2 3 4 5 6 7 = = = = = = = ON/OFF switch USB ports (USB 3.
Working with the notebook Setting up the port replicator Select a suitable location for the port replicator before setting it up. Follow the instructions below when doing so: • • • • Never place the port replicator on a soft surface (e.g. carpeting, upholstered furniture, bed). This can block the air vents of the notebook and cause overheating and damage. Place the port replicator on a stable, flat and non-slip surface. Please note that the port replicator’s rubber feet may mark certain types of surface.
Working with the notebook 1 3 2 ► Position the notebook on the port replicator in such a way that the docking connector on the underside of the notebook is aligned with the docking connector of the port replicator as shown. ► Press down on the notebook’s rear corners so that it locks into position. ► Connect the mains adapter cable to the DC jack (DC IN) of the port replicator (1). ► Connect the power cable to the mains adapter (2). ► Plug the power cable into the mains socket (3).
Working with the notebook Switching on the notebook via the port replicator ► Press the ON/OFF switch on the port replicator to switch the notebook on. Switching off notebook via Port Replicator ► Close all applications and shut down your operating system (please refer to the manual for the operating system). If the notebook cannot be shut down properly, press the ON/OFF button on the Port Replicator for approx. four seconds. The notebook will switch off. Any unsaved data may however be lost.
Working with the notebook Disconnecting the notebook from the port replicator Problems may occur if the notebook is removed from the port replicator during operation. We recommend that you switch off the notebook beforehand or use the Windows function Start – Undock. Windows 7 Problems may occur if the notebook is removed from the port replicator during operation. We recommend that you switch off the notebook beforehand or use the Windows function Start (arrow icon) – Undock.
Security functions Security functions Securityfunctions Your notebook has several security features that you can use to secure your system from unauthorised access. This chapter explains how to use each function, and what the benefits are. Please remember that in some cases, for example, forgetting your password, you may be locked out and unable to access your data.
Security functions Configuring the fingerprint sensor Fingerprintsensor The fingerprint sensor can record an image of a fingerprint. With additional fingerprint software, this image can be processed and used instead of a password. ► You must install the fingerprint software in order to be able to use the fingerprint sensor (1). 1 Using the Security Lock Your device comes with a Security Lock device for the Kensington Lock Cable.
Security functions Configuring password protection in BIOS Setup Utility Before using the various options for password protection in the BIOS Setup utility to increase data security, please observe the following: Make a note of the passwords and keep them in a safe place. If you forget your supervisor password you will not be able to access your notebook. Passwords are not covered by your warranty and a charge will be made for assistance.
Security functions Changing the supervisor or user password You can only change the supervisor password when you have logged into the BIOS Setup Utility with the supervisor password. User password Supervisorpassword Password ► Call the BIOS Setup Utility and go to the Security menu. ► When changing the password, proceed exactly as for password assignment.
Security functions Password protection for the hard disk Passwordprotection: The had disk password prevents unauthorised access to the hard disk drives and is checked internally each time the system is booted. The condition for this is that you have assigned at least the supervisor password. Activating hard disk protection ► Call up the BIOS Setup and select the Security menu.
Security functions Using the security function of the tablet keys If you have allotted a supervisor and/or user password in the form of tablet key combinations as described below, you can use the tablet keys to enter this when you start your device. Setting the Supervisor password ► Select Start - Run. ► Enter the following at the command line: C:\Program Files\Fujitsu\Security Panel Application\Supervisor\FJSECS.EXE. ► Confirm with Enter . ► Follow the instructions on the screen.
Security functions Trusted Platform Module (TPM) (device-dependent) Trusted Platform Module TPM To use the TPM, you must activate the TPM in the BIOS Setup before the software is installed. The condition for this is that you have assigned at least the supervisor password (see "Security functions", Page 68). Enabling TPM • ► ► ► Requirement: You have assigned a supervisor password, see "Security functions", Page 68. Call up the BIOS Setup and select the Security menu.
Connecting external devices Connecting external devices Always refer to the safety information provided in "Important notes", Page 12 before connecting or disconnecting any devices to or from your notebook. Always read the documentation supplied with the device you wish to connect. Never connect or disconnect cables during a thunderstorm. Never pull at a cable when disconnecting it. Always grasp the plug.
Connecting external devices Connecting an external monitor The Port Replicator, available as an option for your notebook, offers you a DVI port and a DisplayPort. An analogue monitor is connected to the analogue VGA monitor port, a digital monitor to the DVI-I monitor port of the port replicator. Screen output is limited to a maximum of two screens at any one time (see "Key combinations", Page 40, section "Toggle output screen").
Connecting external devices Connecting an external monitor to the DisplayPort It is possible to connect a digital monitor to the DisplayPort on the port replicator. Screen output is limited to a maximum of two screens at any one time (see "Key combinations", Page 40, section "Toggle output screen"). Digital DisplayPort ► Switch off the notebook and the external monitor. ► Plug the data cable of the external monitor into the monitor port. ► First switch on the external monitor and then the notebook.
Connecting external devices HDMI port HDMIport The HDMI port on your notebook can be used to connect an external amplifier, LCD TV or a plasma TV with an HDMI connection. ► Connect the data cable to the external device. ► Connect the data cable to the HDMI port of the notebook. Some LCD televisions have only two loudspeaker connections and therefore cannot reproduce Dolby digital or DTS. In order to reproduce the sound, you must go into Windows and adjust the sound settings.
Connecting external devices Connecting USB devices USBports On the USB ports, you can connect external devices that also have a USB port (e.g. a DVD drive, a printer, a scanner or a modem). USB devices are hot-pluggable. This means you can connect and disconnect devices while your operating system is running. USB 1.x has a maximum data transfer rate of 12 Mbit/s. USB 2.0 has a data transfer rate of up to 480 Mbit/s. USB 3.0 has a data transfer rate of up to 5 Gbit/s.
Connecting external devices USB port with charging function (Anytime USB charge) USBchargingfunction It is recommended that the notebook be operated with the power supply connected whenever the USB port with charging function is in use, as this function will drain the battery more quickly if an external USB device is being charged.
Connecting external devices Connecting external audio devices Microphone port/Line In Microphone,connecting Audioports Audiodevices,connecting The microphone port/Line In allows you to connect an external microphone, a MiniDisc player, MP3 player, CD player or a tape deck to your notebook. ► Connect the audio cable to the external device. ► Connect the audio cable to the microphone port/Line In of the notebook.
Removing and installing components during servicing Removing and installing components during servicing Only qualified technicians should repair your notebook. Unauthorised opening or incorrect repair may greatly endanger the user (electric shock, fire risk) and will invalidate your warranty. Servicing Components After consulting the Hotline/Service Desk, you may remove and install the components described in this chapter yourself.
Removing and installing components during servicing Preparing to remove components If you are going to remove or change system components, prepare for the removal as follows: Please observe the safety information in chapter "Important notes", Page 12. Remove the power plug from the mains outlet ! ► Switch the device off. The device must not be in energy-saving mode ! ► Close the LCD screen. ► Remove all the cables from the device. ► Turn the device over and place it on a stable, flat and clean surface.
Removing and installing components during servicing Removing a cover 1 2 ► Remove the screw (1). ► Pull off the cover from the notebook in the direction of the arrow (2). Removing memory modules ► Carefully push the two mounting clips outwards (1). The memory module snaps upwards (2). ► Pull the memory module out of its slot in the direction of the arrow (3).
Removing and installing components during servicing Installing a memory module ► Insert the memory module with the contacts and the recess (a) facing the slot (1). ► Carefully push the memory module downwards until you feel it click into place (2). Memory module expansion 2 1 2 a Attaching the cover 2 1 ► ► ► ► ► Place the cover into position, following the direction of the arrow (1). Fasten the cover with the screw (2). Install the battery again (see "Removing and installing the battery", Page 46).
Removing and installing components during servicing Removing and installing the hard disk Removing a cover 1 2 3 ► Remove the screw (1). Keep the screw in a safe place. If you are removing more than one component at the same time, store the screws for the individual components separate from each other. If you install the wrong screws, components may be damaged. ► Slide the cover in direction of the arrow (2). ► Lift the cover off the notebook (3).
Removing and installing components during servicing Removing a hard disk 2 1 ► To release the hard disk from the contacts, pull it in the direction of the arrow (1). ► Remove the hard disk from the hard disk compartment (2).
Removing and installing components during servicing Installing a hard disk 2 1 ► Place the hard disk into the hard disk compartment (1). ► Push the hard disk in the direction of the arrow (2) until the contacts of the hard disk engage.
Removing and installing components during servicing Attaching the cover 3 2 1 ► Place the cover in the correct mounting position (1). ► Slide the cover in the direction of the arrow (2). ► Tighten the screw (3). Finishing component removal After you have removed or changed the system components as you required, please prepare your device for operation again as follows: ► Install the battery again (see "Inserting battery", Page 47).
Settings in BIOS Setup Utility Settings in BIOS Setup Utility System Setup Hardwareconfiguration BIOS SetupUtility Configuration,BIOSSetupUtility configuration settings,BIOSSetupUtility The BIOS Setup Utility allows you to set the system functions and the hardware configuration for the notebook. When it is delivered, the notebook is set to factory default settings. You can change these settings in BIOS Setup Utility. Any changes you make take effect as soon as you save and exit the BIOS Setup Utility.
Settings in BIOS Setup Utility Exiting BIOS Setup Utility BIOS SetupUtility You need to select the desired option in the Exit menu and activate it by pressing the Enter key: Exit Saving Changes - save changes and exit BIOS Setup Utility ► To save the current menu settings and exit the BIOS Setup Utility, select Exit Saving Changes and Yes. The notebook is rebooted and the new settings come into effect.
Troubleshooting and tips Troubleshooting and tips Fault Tips Troubleshooting Follow the safety notes in the "Safety/Regulations" manual when connecting or disconnecting cables. If a fault occurs, try to correct it as described. If you fail to correct the problem, proceed as follows: ► Make a note of the steps and the circumstances that led to the fault. Also make a note of any error messages displayed. ► Switch the notebook off. ► Please contact the Hotline/Service Desk.
Troubleshooting and tips The notebook’s date or time is incorrect Summer Buffer Dateisincorrect Incorrectdate/time Timenotcorrect Time,daylightsavings battery,load time Cause Time and date are incorrect. If the time and date are still set incorrectly after switching on the notebook. Troubleshooting ► With the BIOS-Setup-Utility, you can set the date and time in the main menu. ► Please contact your sales outlet or our Hotline/Service Desk.
Troubleshooting and tips The LCD screen is difficult to read LCDscreen Cause Reflected glare Troubleshooting ► Turn the notebook or alter the tilt of the LCD screen. ► Increase the brightness of the screen. The external monitor remains blank Monitor Cause Monitor is switched off. Power saving has been activated (monitor is blank). Brightness is set to dark. Screen output is set to the notebook’s LCD screen The external monitor’s power cable or data cable is not connected properly.
Troubleshooting and tips The cursor does not correctly follow the pen movements Cause Pen incorrectly calibrated Fault elimination ► Calibrate the pen as shown under Hardware and Sound / Tablet PC Settings in the Control Panel, see "Setting the pen", Page 33 and "Calibrating the pen", Page 34. Pen input not working Cause Incorrect driver installed. Troubleshooting ► If your device is one which can only be operated using the pen, install the driver for the standard model.
Troubleshooting and tips The notebook stops working Energysaving mode Notebook Cause Notebook is in energy saving mode. An application programme has caused the malfunction. The battery is dead. Troubleshooting ► Leave energy saving mode. ► Close the application program or restart the notebook (by restarting the operating system or switching the device off and back on again). ► Charge the battery. or ► Insert a charged battery. or ► Connect the mains adapter to the notebook.
Troubleshooting and tips The battery discharges too quickly Battery: Cause The battery is either too hot or too cold. In this case the battery indicator flashes. Troubleshooting ► Bring the notebook up/down to a normal temperature again. ► If the operating time of the battery life is extremely short, the battery is probably too old. Replace battery if necessary. You may have an application running that ► Use the mains adapter as frequently as consumes a great deal of power due to frequent possible.
Troubleshooting and tips Error message/cause Resolution Extended memory failed at offset: xxxx Failing Bits: ► Check whether the additional memory zzzz zzzz module has been inserted correctly. When testing the extended memory an error has resulted at the address xxxx. Failure Fixed Disk n ► Start the BIOS Setup (Primary Master submenu) and select the correct settings. The settings of the hard disk drive are incorrect. Keyboard controller error ► Switch the notebook off with the ON/OFF switch.
Technical data Technical data Notebook General Processor Main memory (SO DIMM) 3rd Generation Intel® Core™ with vPro™ technology Maximum 16 Gbyte DDR3 2 slots for 2 Gbyte, 4 Gbyte or 8 Gbyte modules Electrical data Safety regulations complied with Protection class Maximum power draw (when the notebook is switched on and the battery is charged): LCD screen Size Resolution Pixel class Brightness control Technology Digitizer and glass panel WebCam Graphics card Chip Maximum resolution on external display:
Technical data Slots Memory card slot ExpressCard slot SIM card slot Ports Monitor port (analogue) HDMI port LAN port Microphone port/Line In Headphones port/Line Out Docking port USB (Universal Serial Bus) Security Lock Ambient conditions Environment class DIN IEC 721 Mechanism class DIN IEC 721 Operating temperature Transport temperature (2K2) 1 x SD Card 1 x ExpressCard/54 1x 15-pin socket 1x Socket, RJ45 3.5 mm stereo mini jack 3.5 mm stereo mini jack 100-pin socket Total: 3 x USB (1 x USB 3.
Technical data Rechargeable battery You will find information on the batteries used in your device on the Internet at "http://www.fujitsu.com/fts/support/". In addition to the main battery, you can order an optional battery which is inserted in the module slot. All rechargeable batteries are 6-cell batteries. Rated voltage Rated capacity Nominal power Main battery 10.8 V 72.4 Wh 6700 mAh Optional battery (to be inserted in the module bay) 10.8 V 28.
Manufacturer’s notes Manufacturer’s notes Disposal and recycling Notes Information about this subject can be found on your notebook or on our Internet pages. Declarations of Conformity Declarationofconformity The "Declarations of Conformity" for the device can be found on the Internet at: "http://globalsp.ts.fujitsu.com/sites/certificates/default.aspx".
Regulatory Information Notice Changes or modifications not expressly approved by Fujitsu could void this user’s authority to operate the equipment. FCC NOTICES Notice to Users of Radios and Television This equipment has been tested and found to comply with the limit for class B digital devices, pursuant to parts 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Appendix A: WLAN User’s Guide FCC Regulatory Information Please note the following regulatory information related to the optional wireless LAN device. Regulatory Notes and Statements Wireless LAN, Health and Authorization for use Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions, however, are far much less than the electromagnetic energy emissions from wireless devices such as mobile phones.
This device must not be co-located or operated in conjunction with any other antenna or transmitter. For IEEE 802.11a Wireless LAN: For operation within 5.15~5.25 GHz frequency range, it is restricted to indoor environments, and the antenna of this device must be integral. Federal Communications Commission statement This device complies with Part 15 of FCC Rules.
Export restrictions This product or software contains encryption code which may not be exported or transferred from the US or Canada without an approved US Department of Commerce export license. This device complies with Part 15 of FCC Rules., as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation.
Before Using the Optional Wireless LAN This manual describes the procedures required to properly set up and configure the optional integrated Wireless LAN Mini-PCI device (referred to as "WLAN device" in the rest of the manual). Before using the WLAN device, read this manual carefully to ensure its correct operation. Keep this manual in a safe place for future reference.
Wireless LAN Modes Using this Device Ad Hoc Mode "Ad Hoc Mode" refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Point(s). Connectivity is accomplished using only client devices in a peer-to-peer fashion. That is why Ad Hoc networks are also known as peer-to-peer networks.
Access Point (Infrastructure) Mode Infrastructure mode refers to a wireless network architecture in which devices communicate with wireless or wired network devices by communicating through an Access Point. In infrastructure mode, wireless devices can communicate with each other or with a wired network. Corporate wireless networks operate in infrastructure mode because they require access to the WLAN in order to access services, devices, and computers (e.g., file servers, printers, databases).
How to Handle This Device The WLAN device is an optional device that may come pre-installed in your mobile computer. Under normal circumstances, it should not be necessary for you to remove or re-install it. The operating system that your mobile computer comes with has been pre-configured to support the WLAN device. • The Wireless LAN devices support IEEE802.11a, IEEE802.11b, IEEE802.11g, and IEEE802.11n. • The WLAN devices operate in the 2.4 GHz ISM band and the 5 GHz lower, middle, and upper UNII bands.
Deactivation Using the Wireless On/Off Switch The WLAN device can be deactivated quickly and efficiently by toggling the Wireless Device On/Off Switch to the Off position. The switch has no effect on non-Wireless LAN models. Wireless Device Switch Figure 51. Wireless Device On/Off Switch Location Disconnection Using the Icon in the Taskbar Note that disconnecting via the icon in the system tray does not turn off the radio; it continues to transmit and receive even though it’s not connected.
Configuring the Wireless LAN The optional WLAN device can be configured to establish wireless network connectivity using the software that is built into Windows. Support for most industry standard security solutions is contained in this software. Pre-defined parameters will be required for this procedure. Please consult with your network administrator for these parameters: Configuring the WLAN 1 Click the Start button, then select Control Panel.
Troubleshooting the WLAN Troubleshooting Causes and countermeasures for troubles you may encounter while using your wireless LAN are described in the following table.
Problem Unavailable network connection (continued) Possible Cause Possible Solution RF interference from Access Points or other wireless networks The use of identical or overlapping RF channels can cause interference with the operation of the WLAN device. Change the channel of your Access Point to a channel that does not overlap with the interfering device. Wireless network authentication has failed Re-check your Network Authentication, Encryption, and Security settings.
WLAN Specifications Specifications Item Specification Type of network The integrated Intel Centrino Advanced-N 6205 (802.11abgn 2x2) and Atheros XSPAN 802.11a/b/g/n WLAN devices conform to IEEE 802.11a, 802.11b/g, and 802.11n, Wi-Fi based*. Transfer rate (Automatic switching) 54 Mbps maximum data rate (IEEE802.11n to be determined) Active frequency Typical operating distances** Number of channels • • • • • • • • • • 802.11n: 2.4 GHz or 5 GHz 802.11b/g: 2400~2473 MHz 802.11a: 4900 ~ 5850 MHz 802.
Using the Bluetooth Device The Integrated Bluetooth module is a wireless device installed in selected Fujitsu mobile computers. What is Bluetooth Bluetooth technology is designed as a short-range wireless link between mobile devices, such as laptop computers, phones, printers, and cameras. Bluetooth technology is used to create Personal Area Networks (PANs) between devices in short-range of each other.
FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The Bluetooth antenna is exempt from minimum distance criteria due to its low power. The transmitters in this device must not be co-located or operated in conjunction with any other antenna or transmitter. Canadian Notice To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding.
