Communication / Call charges
The PABX generates a call data record for every external call. The call data records contain detailed information
about the call.
For ex.: Date and time, duration of the call, number of the called party, number of the calling party, type of connec
-
tion, communication costs and possible project numbers.
Incoming calls can be logged in two different ways.
·
Only incoming calls with a certain project numer are stored.
·
All incoming calls are stored.
Output of call data records
You have two options to output the stored call data records. For example:
·
output via the RS232 interface on a printer
·
output via the RS232 interface or the USB port on a PC or laptop computer
·
Internal ISDN connection
·
LAN-port
Communication cost display
The communication / call charges can be displayed at any terminal devices that support this feature. ISDN and ana-
log terminal devices use different methods for transmitting and displaying communication costs.
Charge counter
The PABX manages a charge counter for each internal user on the basis of the transmitted charge rate intormation.
The counter logs the costs of all calls. If your network service provider has made this rate information available on
your ISDN connectionthen the PABX terminal devices can display this information. You can also reset the counters.
Charge limitation (Charge limit, pocket money account)
A call charge account can be programmed for each internal user. The charge rate amounts available to that particular
user are defined in this account. If the user uses up his/her allotted units he/she can then only make internal calls. If
this limit is reached during an ongoing call, the call can be completed. The user can make external calls again when
the number of units on his/her account is increased or the counter is deleted.
Terminating an Internet connection from the phone
Using a corresponding operating procedure you can terminate an ongoing Internet connection from any phone.
b #66# q a
Lift up handset Disconnect Internet connection Ack. signal Replace handset
System menu for the PABX
A special menu containing functions typical for the system is provided by the PABX. This menu, and the associated
features, are managed solely from the PABX.
The following features are available in the system menu (Example):
Communication / Call charges Dial authorization with PIN
