User's Manual

Serial No.
Checked By:
Tech
Date
Box 1 - NAVPILOT 711 Wt: 24 lbs Dim: 13.25" x 14" x 28.5"
Part No.
Description Quantity Yes Remarks
1 FAP7002 Processor Unit 1
2 000-157-482 Fuse FGMA 4A 4 SP64-01501
3 000-162-192-10 Cable Tie CV-80N 80mm 20 CP64-03101
4 000-158-850 Self Tapping Screw M4 x 20 4 "
5 IME-727-20Z Installation Manual 1
6 000-167-746 Termination Resistor 1
7 NAVpilot Sample Connection Diagrams 1
8 FAP7011C Control Unit 1
9 White Plastic Cover 1
10 001-081-140 Terminator Plug 1
11 001-081-180 Cable Assembly 15m 1
12 100-352-270 Mounting Sponge 1
13 OME-727-80Z Operator's Manual 1
14 MLG-727-80Z Operator's Guide 1
15
FAP6112
Rudder reference unit w 15M cable
1
PACKING LIST FOR NAVPILOT 711C
NAVPILOT 711
For Internal Use Only
FAP7011C
FAP6112
15
FAP6112
Rudder
reference
unit
w
15M
cable
1
16 100-328-060 500mm Threaded Connecting rod 1
17 009-001-180 Red End Bearing (RTB6) 2
18 100-328-110 Spacer, 11 mm oa 1
19 000-158-853 Hex Bolt, M6 x 40 2
20 000-158-854 Flat Washer M6 6
21 000-158-855 Spring Washer M6 2
22 000-158-856 Hex Nut, M6 6
23 000-158-850 Self Tapping Screw M4 x 20 3
24 PG700 Integrated Heading Sensor 1
25 000-167-964 NMEA2000 Micro Cable 6M 1 CP64-02800
26 000-162-605 Self Tapping Screws M4 x 16 3 "
27 000-158-856 Hex Nut, M6 6
28 000-158-850 Self Tapping Screw M4 x 20 3
rev 6/14
FAP6112
PG700
Page 1 of 1
