Installation Instructions

5
AMPLIFIER SPECIFICATIONS
Specifications
PP-AM10001 PP-AM15001 PP-AM20001 PP-AM4002
MAX Power Rating
(Watts/Channel)
1000 1500 2000 400
MAX Current 70A 100A 100A 30A
Full Rated Power Distortion
(Max) 1kHz
0.11% 0.15% 0.45% 0.05%
THD @ Rated Power
1kHz/100Hz
0.1% 0.1% 0.3% 0.1%
Channel Separation — — — 50
Frequency Response Hz
(-3dB)
10Hz – 250Hz 10Hz – 250Hz 10Hz – 250Hz
10Hz – 40kHz
Signal To Noise >90 >90 >90 >90
Variable High Pass Filters — — — 12dB/Octave
Variable Low Pass Filters 12dB/Octave 12dB/Octave 12dB/Octave 12dB/Octave
Bass Boost @ 45Hz 0 –12dB 0 –12dB 0 –12dB 0 –12dB
Input Sensitivity 0.2 – 8V 0.2 – 8V 0.2 – 8V 0.2 – 8V
Input Impedance — 47K 47K 47K
Fuse Rating 35A x 2 25A x 4 25A x 4 30A
Specifications
PP-AM9002 PP-AM12002 PP-AM8004 PP-AM16004
MAX Power Rating
(Watts/Channel)
900 1200 800 1600
MAX Current 60A 75A 60A 105A
Full Rated Power Distortion
(Max) 1kHz
0.04% 0.04% 0.04% 0.08%
THD @ Rated Power
1kHz/100Hz
0.1% 0.1% 0.1% 0.1%
Channel Separation 50 50 50 50
Frequency Response Hz
(-3dB)
10Hz – 40kHz 10Hz – 40kHz 10Hz – 40kHz 10Hz – 40kHz
Signal To Noise >90 >90 >90 >90
Variable High Pass Filter 12dB/Octave 12dB/Octave 12dB/Octave 12dB/Octave
Variable Low Pass Filter 12dB/Octave 12dB/Octave 12dB/Octave 12dB/Octave
Bass Boost @ 45Hz 0 – 12dB 0 – 12dB 0 – 12dB 0 – 12dB
Input Sensitivity 0.2 – 8V 0.2 – 8V 0.2 – 8V 0.2 – 8V
Input Impedance 47K 47K 47K 47K
Fuse Rating 30A x 2 25A x 3 25A x 3 35A x 3
