3.18 Menu structure overview
* GARDENA R130Li, R130LiC, R160Li, R160LiC
Timer
Overview/Monday
Period 1 Period 2 Copy
Su Current
day
All weekSaFrThWeTuMoAll
days
Reset
** GARDENA R100LiC, R130LiC, R160LiC
On/Off
Low Medium High
Cutting time
SensorControl*
Smart system**
Good Poor Bad
Connected
Yes/No
Signal
strength
Status
Exclude
device
Security
Low Medium High
Change
PIN code
New loop
signal
Security level
Advanced
