Operator's manual SILENO (R100Li), smart SILENO (R100LiC), SILENO+ (R130Li, R160Li), smart SILENO+ (R130LiC, R160LiC) Read the operator's manual carefully and make sure that you understand the instructions before you use the product.
Contents 1 Introduction 1.1 Memo..................................................................... 3 1.2 Product description................................................ 3 1.3 Product overview....................................................5 1.4 Symbols on the product......................................... 6 2 Safety 2.1 Safety definitions....................................................7 2.2 General safety instructions.....................................7 2.
1 Introduction 1.1 Memo Serial number: PIN code: Product registration key: The Product registration key is a valuable document and must be stored in a safe place. This key is necessary for example to register the product on GARDENA's website or unlock the robotic lawnmower in the event of a lost PIN code. The product registration key is provided in a separate document in the product packaging. If the robotic lawnmower is stolen, it is important to notify GARDENA of this.
1.2.4 Movement pattern The movement pattern of the robotic lawnmower is random, which means that a movement pattern is never repeated. With this cutting system the lawn is mown evenly without any mowing lines from the robotic lawnmower. The blades must be in good condition to obtain the best mowing result. In order to keep the blades sharp for as long as possible it is important to keep the lawn free from branches, small stones and other objects. Replace the blades regularly for the best mowing result.
1.3 Product overview 3 4 1 9 2 8 7 5 10 6 19 14 12 18 11 13 34 15 29 20 17 33 31 27 21 16 22 28 25 26 30 24 23 32 The numbers in the figure represent: 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19.
1.4 Symbols on the product These symbols can be found on the robotic lawnmower. Study them carefully. WARNING: Read the user instructions before operating the robotic lawnmower. WARNING: Operate the disabling device before working on or lifting the machine. The robotic lawnmower can only start when the main switch is set to 1 and the correct PIN code has been entered. Turn the main switch to 0 before carrying out any inspections and/or maintenance.
2 Safety 2.1 Safety definitions 2.2 General safety instructions Warnings, cautions and notes are used to point out specially important parts of the operator's manual. The following system is used in the Operator’s Manual to make it easier to use: WARNING: Used if there is a risk of injury or death for the operator or bystanders if the instructions in the manual are not obeyed.
Warning! Automatic lawnmower! Keep away from the machine! Supervise children! • • Warning! Automatic lawnmower! Keep away from the machine! Supervise children! • • • • • • Use the PARK function or switch off the main switch when persons, especially children or pets, are in the cutting area. It is recommended to program the lawnmower for use during hours when the area is free from activity, e.g. at night. See Timer on page 22.
2.3.4 In the event of a thunderstorm 3. Carry the robotic lawnmower by the handle under the robotic lawnmower with the blade disc away from the body. To reduce the risk of damage to electrical components in the robotic lawnmower and its charging station, we recommend that all connections to the charging station are disconnected (power supply, boundary wire and guide wires) if there is a risk of a thunderstorm. CAUTION: Do not lift the robotic lawnmower when it is parked in the charging station.
3 Installation 3.1 Presentation GARDENA R100Li/LiC, R130Li/LiC, R160Li/LiC This operator's manual covers SILENO and SILENO+ products. Within the SILENO family you find R100Li and R100LiC. Within the SILENO+ family you find R130Li, R130LiC, R160Li and R160LiC. The C in the model designation refers to the GARDENA smart system. This manual will henceforward refer to the model specific names. GARDENA SILENO R100Li 1000 m2 R100LiC 1000 m2, smart system SILENO+ R130Li Smart Gateway power supply √ 3.1.
3.2 Preparations Read through this entire chapter before beginning the installation. How the installation is done also affects how well the robotic lawnmower works. It is therefore important to plan the installation carefully. Planning is simplified if you make a sketch of the working area, including all obstacles. This makes it easier to see the ideal positions for the charging station, the boundary wire and the guide wire. Draw on the sketch where the boundary and guide wires should be routed. 3.
Do not put the charging station in confined spaces or in a corner. This can make it difficult for the robotic mower to find the charging station. 3.3.2 Connecting the power supply The charging station must be positioned on relatively level ground. The front end of the charging station cannot be positioned higher or lower than the back end according to picture below. max. 5 cm / 2" max. 5 cm / 2" The charging station must not be positioned in a way that can bend its base plate.
The low voltage cable must never be stored in a coil or under the charging station's base plate as this can interfere with the signals from the charging station. WARNING: Do not under any circumstances mount the power supply at a height where there is a risk it can be submerged in water (minimum 30 cm from the ground). It is not permitted to place the power supply on the ground. 3. Connect the power supply’s power cable to a 100-240V wall socket.
3.4 Charging the battery When the charging station is connected, it is possible to charge the robotic lawnmower. Set the main switch to position 1. Place the robotic lawnmower in the charging station while the boundary and guide wires are being laid. If the battery is flat, it takes around 80 to 100 minutes to fully charge it. 10 cm / 4" 0 cm / 0" WARNING: Only charge the robotic lawnmower using a charging station which is intended for it.
to excessive wear on the robotic lawnmower. About 15 cm of the lawn along the ditch/kerbstone will not be mown. robotic lawnmower from ending up outside the working area under any circumstance. min. 15 cm / 6" 20 cm / 8" 1-5 cm / 0.4-2" If the working area borders on a paving stone path or similar that is level with the lawn (+/- 1 cm), it is possible to allow the robotic lawnmower to run a little over the path. The boundary wire should then be laid 10 cm from the edge of the path.
0-15% 0-15 cm / 0-6" 3.5.3.1 Secondary areas If the working area consists of two areas which the robotic lawnmower has difficulty travelling between, it is recommended to set up a secondary area. Instances of this are 40% slopes or a passage that is narrower than 60 cm. Lay the boundary wire then around the secondary area so that it forms an island outside of the main area. The robotic lawnmower must be moved manually between the main and secondary area when the lawn in the secondary area has to be cut.
• Use a hammer to knock the pegs into the ground. Exercise care when knocking the pegs and make sure the wire is not under strain. Avoid sharp bends. If the boundary wire is to be buried: • 15- cm / 6-" 100 cm / 40" Make sure to lay the boundary wire at a minimum of 1 cm and a maximum of 20 cm in the ground. The wire can be buried for instance using an edge cutter or a straight spade. Note: Extra wire must not be placed in coils outside the boundary wire. This can disrupt the robotic lawnmower.
1. 2. 2. Press the connectors together using a pair of pliers. Press until you hear a click. 3.5.4.3 Splicing the boundary wire CAUTION: Twinned cables, or a screw terminal block that is insulated with insulation tape are not satisfactory splices. Soil moisture will cause the wire to oxidise and after a time result in a broken circuit. 3. Cut off any surplus boundary wire. Cut 1-2 cm above each connector. Use an original coupler if the boundary wire is not long enough and needs to be spliced.
2. 3. 4. The robotic lawnmower runs at varying distances from the guide wire to reduce the risk of tracks forming. The area beside the wire which the robotic lawnmower then uses is called the Corridor. The wider the corridor allowed by the installation, the less the risk of tracks forming. The robotic lawnmower always runs to the left of the guide wire as seen facing the charging station. Thus the corridor is to the left of the guide wire.
wire as outlined in the previous description. See Laying the boundary wire on page 17. 3.8 Checking the installation Check the loop signal by inspecting the indicator lamp on the charging station. See Indicator lamp in the charging station on page 47 if the lamp does not indicate a solid or flashing green light. 8. Connect the guide wire to the boundary wire using a coupler: a) Insert the boundary wire and guide wire in the coupler.
• • • • • • The START button is used to activate the robotic lawnmower. This is normally the last button to be pressed before closing the hatch. The BACK and OK buttons are used to navigate in the menu. The OK button is also used to confirm settings. The arrow keys are used to navigate in the menu but also to make selections in certain setting options. The MENU button is used to go to the main menu. The PARK button is used to send the robotic lawnmower to the charging station.
SensorControl 3.12 Timer Only for R130Li, R130LiC, R160Li and R160LiC TIMER This function allows the robotic lawnmower to automatically adjust its mowing times based on how quick the lawn grows. When the weather is good for grass growth, the robotic lawnmower mowes more often and when the grass growth is slower the robotic lawnmower will automatically spend less time on the lawn. See SensorControl on page 24.
• • Work hours per day shows how many hours a day the robotic lawnmower will be allowed to work for the selected amount of work days. Suggested time interval shows a time interval that corresponds to the required work hours per day. It is possible to configure 2 work periods a day. There can be unique work periods in each day, but it is also possible to copy the current day’s work period to all the other days. 3.12.
lawnmower will automatically spend less time on the lawn. The first mowing cycle of the day will however always be completed. After that, SensorControl will decide whether to continue or not. To disable mowing a whole day, uncheck both periods. 3.12.5 Copy Use this function to copy the current day settings to other days. Mark Copy by using arrow keys and press OK. Then use the up and down arrow keys to move the cursor between days. The times will be copied to the days that are marked with OK.
3.14.5 Status SMART SYSTEM Connected Yes/No Status Exclude device Signal strength Status The GARDENA smart system makes wireless interaction between your smart robotic lawnmower and other GARDENA smart system devices, such as smart Water Control and smart Sensor possible. In this Options Menu, you can: • • enable your smart robotic lawnmower to include with or exclude from the GARDENA smart system App. check the status of the wireless connection to the smart system.
Low and Medium security prohibits access to the robotic lawnmower if the PIN code is unknown. High security also includes a warning that beeps if the correct PIN code is not entered after a designated time period. If the wrong PIN code is entered 5 times in succession the robotic lawnmower is blocked for a time. The blockage time is extended for every new incorrect attempt. Function Low Medium High Time lock X X X X X PIN request Alarm X 3.15.2.
number of times it leaves the charging station. At all other times, the robotic lawnmower starts to mow at the charging station. Lawn coverage Area 1, 2 or 3 Select the percentage that corresponds to the size of the remote area relative to the total working area. If the remote area is for instance half of the total working area, 50% must be selected. A lower figure must be specified if the remote area is smaller. If more areas are used, take into account that the total figure cannot exceed 100%.
3.16.1.7 How to measure the distance to a remote area 1. Park the robotic lawnmower in the charging station. 2. In the Area 1, 2 or 3 > How far? menu function, enter a distance which beyond any doubt exceeds the real figure. The maximum distance that can be entered is 500 metres. 3. Select Area 1, 2 or 3 > More > Test and press OK. 4. Press START and close the hatch. 5. Press STOP at the required position. The distance is now shown in the display. This figure can now be saved in Area 1, 2 or 3 > How far?.
3.16.2.4 Exit angles > Sectors The robotic lawnmower can be set for 1 or 2 exit sectors. If the charging station is placed in a passage, 2 exit angles, for instance 70° - 110° and 250° - 290°, can be used. When 2 exit angles are used, there is a need to also specify how often the robotic lawnmower must leave the charging station in Sector 1. This is done using the Proportion function by initially specifying a percentage.
Time & Date Set time Set date Time format Date format • • • • 3.17.2.3 Country With this function you can select in what country the robotic lawnmower will work. Place the cursor at the required country and press OK. 3.17.2.4 Reset all user settings This function allows you to reset the robotic lawnmower to the factory default settings. Set time: Enter the correct time and press OK to The following settings are however not altered: Set date: Enter correct date and press OK to exit.
3.18 Menu structure overview Timer Overview/Monday Period 1 All Mo days Period 2 Tu We Th Copy Fr Sa Reset Su Current day All week SensorControl* Cutting time On/Off Low Medium High Smart system** Exclude device Status Connected Yes/No Signal strength Good Poor Bad Security Advanced Security level Low Medium High New loop signal Change PIN code * GARDENA R130Li, R130LiC, R160Li, R160LiC ** GARDENA R100LiC, R130LiC, R160LiC 307 - 002 - 11.10.
3.19 Menu structure overview Installation Lawn coverage Advanced Area 1-3 How? How far? How often? Disable More Test Reset Corridor width Exit angles Reversing distance Drive past wire Settings ECO mode General On/Off 32 - Installation Time & date Language Set time Set date Country Time format Reset all user setting About Date format 307 - 002 - 11.10.
3.20 Yard layout examples The robotic mower’s behaviour is controlled to a certain extent by what settings are made. Adapting the robotic lawnmower's settings according to the shape of the lawn makes it easier for the robotic lawnmower to frequently reach all parts and therefore achieve a perfect mowing result. Different layouts require different settings. The following pages outline a number of layout examples with installation proposals and settings.
3.20.
3.20.5 Unsymmetrical working area with a narrow passage and a number of islands Area 800 m2 Timer R100Li, R100LiC 07:00 - 24:00, Monday to Saturday R130Li, R130LiC, R160Li, R160LiC 08:00 - 22:00, Monday to Saturday Lawn coverage Factory setting Remarks The guide wire must be placed along the narrow passage to ensure that the robotic lawnmower can with ease locate the charging station from the right hand side of the working area.
3.20.7 A secondary area Area 500 + 100 m2 Timer R100Li, R100LiC: 08:00 - 20:30, Monday, Tuesday, Thursday, Friday, Saturday R130Li, R130LiC, R160Li, R160LiC: 08:00 - 18:30, Monday, Tuesday, Thursday, Friday, Saturday Lawn coverage Factory setting Remarks The secondary area is cut using the Secondary area mode on Wednesday and Sunday. 36 - Installation 307 - 002 - 11.10.
4 Operation 4.1 Main switch WARNING: Read the safety instructions carefully before you start your robotic lawnmower. WARNING: Keep your hands and feet away from the rotating blades. Never put your hands or feet close to or under the body when the motor is running. Note: Always press the START button before closing the hatch to start the robotic lawnmower. 4.3 Operating mode - Start When the START button has been pressed the following operation selections can be selected.
4.4.2 Start with next timer The robotic lawnmower stays in the charging station until the next Timer setting permits operation. This operation selection is suitable if one wishes to cancel an ongoing mowing cycle and allow the robotic lawnmower to stay in the charging station until the next day. 4.5 Stop 1. Press the STOP button. The robotic lawnmower stops, the blade motor stops and the hatch opens.
4.8 Charge a flat battery 24 h When the GARDENA robotic lawnmower is new or has been stored for a long period, the battery will be flat and needs to be charged before starting. WARNING: Only charge the robotic lawnmower using a charging station which is intended for it. Incorrect use may result in electric shock, overheating or leakage of corrosive liquid from the battery.
5 Maintenance 5.1 Introduction - maintenance For better operating reliability and longer service life: check and clean the robotic lawnmower regularly and replace worn parts if necessary. All maintenance and servicing must be done according to GARDENA's instructions. See Guarantee terms on page 54. When the robotic lawnmower is first used, the blade disc and blades should be inspected once a week. If the amount of wear during this period has been low, the inspection interval can be increased. 5.2.
5.3.1 To replace the blades 1. Set the main switch to position 0. 2. Turn the robotic lawnmower upside down. Place the robotic lawnmower on a soft and clean surface to avoid scratching the body and the hatch. 3. Remove the 3 screws. Use a straight slot or crosstip screwdriver. 2. Set the main switch to position 1 and place the mower standing on all wheels. 3. Follow the software update instructions from your received email. 4.
1. Set the main switch to position 0. 2. Turn the robotic lawnmower upside down. Place the robotic lawnmower on a soft and clean surface to avoid scratching the body and the display cover. 3. Clean around the battery cover. 4. Unscrew the four screws to the battery cover (Torx 20) and remove the battery cover. 5. Carefully lift out the battery and release the connectors. NOTE! Do not pull the cables. Hold the connectors and release the latch. 6.
6 Troubleshooting 6.1 Introduction - troubleshooting In this chapter, a number of messages are listed which may be shown in the display if there is a malfunction. There is a proposal as to the cause and steps to take for each message. This chapter also presents some symptoms that can guide you if the robotic lawnmower does not work as expected. More suggestions for steps to take in the event of malfunction or symptoms can be found on www.gardena.com. 6.
Message Cause Outside working area The boundary wire connections to the charging station are crossed. Action Check that the boundary wire is connected correctly. The boundary wire is too close to the edge of Check that the boundary wire has been laid the working area. according to the instructions. See Installation on page 26. The working area slopes too much by the boundary loop. The boundary wire is laid in the wrong direction around an island.
Message Cause Action Stuck in charging sta- There is an object in the way of the robotic tion lawnmower preventing it from leaving the charging station. Remove the object. Upside down Turn the robotic lawnmower the right way up. The robotic lawnmower is leaning too much or has turned over. Needs manual charg- The robotic lawnmower is set to the Seconing dary area operating mode. Place the robotic lawnmower in the charging station. This behaviour is normal and no action is required.
Message Cause Action Connectivity problem Potential problem on the connectivity circuit board in the mower. Restart the mower. If the problem remains, the message requires action by authorized service technician. Connectivity settings restored The connectivity settings was restored due to Please check and change the settings if neea fault. ded. Poor signal quality The connectivity circuit board in the mower is Verify the mower is not upside down or tilted.
6.4 Indicator lamp in the charging station For a fully functional installation, the indicator lamp in the charging station must emit a solid or flashing green light. If something else appears, follow the troubleshooting guide below. There is more help on www.gardena.com. If you still need help, please contact your local GARDENA representative. Light Cause Action Solid green light Good signals No action required Green flashing light The signals are good and ECO mode is activated. No action required.
Symptoms Cause Action The robotic lawnmow- The robotic lawnmower searches for the er runs, but the blade charging station. disc does not rotate. No action. The blade disc does not rotate when the robotic lawnmower is searching for the charging station. The robotic lawnmow- Grass or other foreign object blocks the blade Remove and clean the blade disc. See Clean er mows for shorter disc. the robotic lawnmower on page 40. periods than usual The battery is spent. Replace the battery.
boundary loop. See Indicator lamp in the charging station on page 47. To rectify the fault you will need boundary wire, connector(s) and coupler(s): a) If the suspected boundary wire is short then it is easiest to exchange all of the boundary wire between AL and the point where the guide wire is connected to the boundary wire (thick black line). 2. Check that the boundary wire connections to the charging station are properly connected and not damaged.
Continue until only a very short section of the wire remains which is the difference between a solid green light and a flashing blue light. Then follow instruction in step 5 below. 4. If indicator lamp still flashes blue in step 3 above: Put AL and G1 back in their original positions. Then switch AR and G1. If indicator lamp now is lit with a solid green light then disconnect AL and connect a new boundary wire to AL. Connect the other end of this new wire at the middle of the suspected wire section.
7 Transportation, storage and disposal 7.1 Transportation The contained lithium-ion-batteries are subject to the Dangerous Goods Legislation requirements. For commercial transports e.g. by third parties or forwarding agents, special requirement on packaging and labeling must be observed. Consult an expert for hazardous material for preparation of the item being shipped. Please also observe possibly more detailed national regulations.
8 Technical data 8.1 Technical data Data R100Li, R100LiC R130Li, R130LiC R160Li, R160LiC Model series SILENO, smart SILENO SILENO+, smart SILENO+ SILENO+, smart SILENO+ Length, cm 63 63 63 Width, cm 51 51 51 Height, cm 25 25 25 Weight, kg 9.8 9.8 9.8 Dimensions Electrical system Battery, Lithium-Ion 18 V/2.1 Ah Art.No 584 85 28-01, 584 85 28-02 Power supply, V/28 V DC 100-240 100-240 100-240 Low voltage cable length, m 10 10 10 Mean energy consumption at maximum use 7.
Data R100Li, R100LiC R130Li, R130LiC R160Li, R160LiC Mowing Cutting system Blade motor speed, rpm 3 pivoted cutting blades 2300 2300 2300 Power consumption 25 during cutting, W +/20 % 25 25 Cutting height, cm 2-6 2-6 2-6 Cutting width, cm 22 22 22 Narrowest possible passage, cm 60 60 60 Maximum angle for cutting area, % 35 35 35 Maximum angle for boundary wire, % 15 15 15 Maximum length boundary wire, m 800 800 800 Maximum length guide wire, m 400 400 400 Working capac
9 Warranty 9.1 Guarantee terms GARDENA guarantees this product’s functionality for a period of two years (from date of purchase). The guarantee covers serious faults relating to materials or manufacturing faults. Within the guarantee period, we will replace the product or repair it at no charge if the following terms are met: • • The robotic lawnmower and the charging station may only be used in compliance with the instructions in this Operator’s Manual.
10 EC Declaration of Conformity 10.1 EC Declaration of Conformity Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares that the Robotic lawnmovers R100Li, R130Li, R160Li, R100LiC, R130LiC and R160LiC with serial numbers dating 2017 week 37 and onwards (the year and week is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVE: • Directive “relating to machinery” 2006/42/EC.
