Time & Date Set time
Set date
Time format
Date format
•
Set time:
Enter the correct time and press OK to
exit.
•
Set date:
Enter correct date and press OK to exit.
•
Time format:
Place the cursor at the required time
format: 12h 24h. Press OK to exit.
•
Date format:
Place the cursor at the required date
format:
YYYY-MM-DD (year-month-day)
MM-DD-YYYY (month-day-year)
DD-MM-YYYY (day-month-year)
Exit by pressing OK.
3.17.2.2 Language
Set language with this function.
To select language: Place the cursor at the required
language and press OK.
3.17.2.3 Country
With this function you can select in what country the
robotic lawnmower will work.
Place the cursor at the required country and press OK.
3.17.2.4 Reset all user settings
This function allows you to reset the robotic lawnmower
to the factory default settings.
The following settings are however not altered:
• Security level
• PIN code
• Loop signal
• Date & Time
• Language
• Country
1. Select
Reset all user settings
in the menu and press
OK.
2. Confirm by pressing OK.
3.17.2.5 About
The
About
menu displays information about the robotic
lawnmower's serial number and different software
versions.
30 - Installation 307 - 002 - 11.10.2017
