PS200 Series

QUICK OPERATING INSTRUCTIONS

Switch ON

•

Press and hold the Right Hand button

for one second to switch the instrument ON and

initiate a warm-up routine.

• The display will show the serial number,

software version, battery status and calibration

gas. Next, the date and time are shown, followed

by the Calibration Due date. If expired, press the

button to acknowledge.

• Lastly, a sensor check is run. If sensors are

working OK and were zeroed correctly, a

symbol is displayed adjacent to the gas type. If a

sensor fails the zero check, the display will be

red, the audible / visual alarms activate and a

symbol is displayed adjacent to the faulty gas type.

To acknowledge this fault, press the

button.

Switch ON - Manual Bump Test

Press and hold the button to switch the

instrument ON and initiate a Manual Bump Test

(after the warm-up routine is complete). When

concluded, the instrument will operate as normal.

Refer to Essential Health and Safety Requirement (EHSR) and PS200

Series User Handbook before first use.

Backlight / MAX & MIN

Press the button once to switch the backlight

ON. (After 20 seconds it will automatically switch

OFF.) Press again to view MAX readings and a further

press to view the MIN readings. To reset MAX / MIN

readings, press and hold the

button for 2

seconds when either MAX / MIN screen is displayed.

Alarms Reset / Acknowledge

In alarm condition, the display will be red and the

audible and visual alarms are activated. When the

gas readings (of a Latching Alarm) are safe, press

and hold the

button to reset / acknowledge the

alarm. (If alarms are Non-Latching, the audible and

visual alarms reset automatically when gas readings

are safe.)

Normal Operation

The standard operating screen for the 4 Gas model

is shown here. Other models will report the relevant

gases they are capable of detecting.

Switch Pump ON / OFF

Press and hold the button to toggle the pump ON / OFF

(Pumped instruments only).

Manual Datalog

Press the button once to perform a manual datalog, briefly indicated on

the display as ‘LOGGING’.

Switch OFF

Press and hold both and buttons, for 3 seconds, to switch the

instrument OFF.

Summary of content (2 pages)

PAGE 1
PS200 Series QUICK OPERATING INSTRUCTIONS Refer to Essential Health and Safety Requirement (EHSR) and PS200 Series User Handbook before first use. Switch ON • Press and hold the Right Hand button for one second to switch the instrument ON and initiate a warm-up routine. • The display will show the serial number, software version, battery status and calibration gas. Next, the date and time are shown, followed by the Calibration Due date. If expired, press the button to acknowledge.
PAGE 2
WARNINGS CHARGING LOW BATTERY Flashes when approximately 30 minutes operating time remains. The display flashes red, the audible alarm sounds once every two seconds and the red LED’s flash. Note: Gas alarms will continue to operate as normal. BAT FAULT Before first use the PS200 instrument should be charged for up to 4 hours or until the ‘CHARGE COMPLETE’ message appears on the display. The PS200 Series uses a Li-Ion (Lithium Ion) rechargeable battery.
